Control inputs and outputs

8.1

Analog input EM S1INA

8.1.1 General

The analog input of the EM-ABS-01 extension module can be used as a voltage input.
Parameterization of the input signal is done via the definition of a linear characteristic
and assignment as
− Reference value source
(selectable via parameter
−
Reference percentage source
(selectable via parameter
−
Actual percentage source
(selectable via parameter
or
− limit value sources
(can be selected via the parameters 734 ... 737).

8.1.2 Characteristic

Mapping of the analog input signal onto a reference frequency value or a reference
percentage value is possible for various requirements. Parameterization is to be done
via two points of the linear characteristic of the reference value channel.
The characteristic point 1, with the coordinates X1 and Y1, and the characteristic point
2, with the coordinates X2 and Y2, can be set in four parameters.
Points X1 and X2 are stated in per cent, as the analog input can be switched as a
current or voltage input via switch S3.
No.
564
565
566
567
The coordinates of the points relate, as a percentage, to the analog signal with 10 V
or 20 mA and parameter
Percentage
frequency inverter and/or by selection of the points.
The definition of the analog input characteristic can be calculated via the two-point
form of the line equation. The speed Y of the drive is controlled ac-cording to the ana-
log control signal X.
Attention! The monitoring of the analog input signal via parameter
84
Reference frequency source
Reference percentage source
Actual percentage source
Parameters
Description
Point X1
Point Y1
Point X2
Point Y2
Maximum Frequency
519. The direction of rotation can be changed via the digital inputs of the
Y
563 demands examination of the characteristic parameters.
behavior
Sensible use is only possible if
EM-ABS-01 for ACU
Min.
-100,00 %
-100,00 %
-100,00 %
-100,00 %
419 or parameter
( )
Y2 - Y1
= ⋅ − +
X X1 Y1
X2 - X1
564 is in the positive range.
Point X1
475),
476),
478, in configuration x11)
Settings
Max. Factory set-
ting
100,00 % -98,00 %
100,00 % -100,00 %
100,00 % 98,00 %
100,00 % 100,00 %
Maximum Reference
Error/Warning
