5.3.3.2

Looping via terminals X410A

In some cases, encoder power supply must be supported or effected by an external
power supply. This is a good idea especially in the case of encoders with medium
power demand (0.5...2 W) or when many consumers are connected to the signal ter-
minals.
An external DC 24 V power supply can be connected to terminals X410A.1 (DC 24 V)
and X410A.2 (ground). Via this power supply, a connected encoder can be powered.
BONFIGLIOLI VECTRON recommends connecting an external power supply.
Input voltage range
Rated input current
Peak inrush current
External fuse
Safety
Note:
Caution! If the encoder is powered via X410A, 2 W power are available to the en-
Caution! The inputs for the external power supply can withstand external voltage up
Caution! Some encoders (e.g. laser distance meters) need more power than possi-
Set parameter
See chapter 8.4.3 "Power supply".
The voltage level can be set up via parameter
8.4.4 "Supply voltage".
The encoder can be powered as follows:
via control terminals X410A.5 (DC 5 ... 12 V) and X410A.7 (GND) or
−
via contacts X412.6 (V
−
See chapter 5.3.2 "Control terminals".
03/12
Requirements to be met by external power supply
DC 24 V ±10%
Max. DC 1.0 A (typical DC 0.45 A),
Typically: < DC 20 A
Standard fuse elements for rated current, characteristic:
slow
Safety extra low voltage (SELV) according to EN 61800-
5-1
Connect the power supply for the encoder to terminals X410A.1 and
X410A.2. Connection via the terminals of the basic device ACU (X210A.1
and X210A.2) is not sufficient for powering the EM-ABS-01 module and the
encoder.
coder interface. Another 2 W are available to the interfaces (digital/analog
inputs/outputs) of the basic device.
to DC 30 V. Avoid higher voltage levels. Higher voltages may destroy the
module.
ble with the power supply described here. If the encoder requires a power
level higher than 2 W or more than DC 12 V, it must be connected to an
external power supply directly. Non-fulfillment of this requirement may
result in dangerous plant states.
1186 to either "2 - via X410A" or "6 via X410A, sense".
Power supply
) and X412.15 (GND) of the female HD-Sub-D connector.
Enc
EM-ABS-01 for ACU
1187. See chapter
Supply voltage
27
