5.3.2 Control terminals

The control and software functionality can be configured as required to ensure a reli-
able and economical operation.
Caution! Switch off power supply before connecting or disconnecting the control
Atten-
tion!
Terminal
1
2
3
4
5
6
7
Terminal
1
2
3
4
5
6
7
1)
The control electronics parameters can be configured as required.
2)
The max. power available is reduced by the other used control outputs of the frequency
inverter and extension module. For sufficient power, connect an external power source to
the DC 24 V voltage input.
The voltage value can be adjusted via parameter
Caution! The input for external DC 24 V voltage supply can withstand external vol-
Caution! The power output on terminal X410A.1 may be loaded with a maximum
03/12
Extension module EM-ABS-01
inputs and outputs.
In order to minimize electromagnetic interference and to obtain a good
signal quality, the shield of the cable is to be connected to ground on a
plane at both ends.
Control terminal X410A
DC 24 V voltage input
Ground (GND) DC 24 V
Digital output EM-S1OUTD
Digital output EM-S21OUTD
DC 5 ... 12 V voltage output
Analog input EM-S1INA
Ground DC 10 V
Control terminal X410B
Ground (GND)
Digital input EM-S1IND
Digital input EM-S2IND
Digital input EM-S3IND
System bus, CAN low
System bus, CAN high
Ground (GND)
tage up to DC 30 V. Avoid higher voltage levels. Higher voltages may de-
stroy the module.
power of 2 W. Higher power levels can damage components of the mod-
ule.
EM-ABS-01 for ACU
Wieland DST85 / RM3,5
0.2 ... 0.3 Nm
1.8 ... 2.7 lb-in
Description
1)
1)
2)
1)
Description
1)
1)
1)
Supply voltage
2
0.14 ... 1.5 mm
AWG 30 ... 16
2
0.14 ... 1.5 mm
AWG 30 ... 16
2
0.25 ... 1.0 mm
AWG 22 ... 18
2
0.25 ... 0.75 mm
AWG 22 ... 20
1187.
21
