22 Dig. encoder: Transmitter current
23 Dig. encoder: Overtemperature
24 Dig. encoder: timeout
25 Dig. encoder: CRC error
2A Dig. encoder: SSI error bits (Low)
2B Dig. encoder: SSI error bits (High)
2C Dig. encoder: SSI transmission error 1
2D Dig. encoder: SSI transmission error 2
F21 nn Fault report to system bus master in fault in system bus slave
F22 00 Communication fault, system bus, timeout SYNC telegram
01 Communication fault, system bus, timeout RxPDO1
02 Communication fault, system bus, timeout RxPDO2
03 Communication fault, system bus, timeout RxPDO3
10 Communication fault, system bus, bus OFF
Note:
The error messages described above may occur depending on the encoder connected.
Not every error message will be used for every encoder system.
Additional fault messages are described in the Operating instructions of the frequency
inverter.
In addition to fault messages mentioned, there are further fault messages. However
these messages are only used for internal purposes and are not listed here. If you
receive fault messages which are not listed here, please contact Bonfiglioli.
03/12
Transmitter current in critical range.
Encoder temperature too high
Communication between EM-ABS-01 and encoder resulted in a timeout
error.
Communication between EM-ABS-01 and encoder resulted in a CRC error.
Error bit of SSI encoder according to
set.
Error bit of SSI encoder according to
is set.
A SSI encoder transmission error has occurred.
A SSI encoder transmission error has occurred.
nn = Node ID of slave (hex)
EM-ABS-01 for ACU
SSI: Error-/Extra-Bits (Low)
SSI: Error-/Extra-Bits (High)
1269 is
1270
