Digital inputs (X410B.2) ... (X210B.4):
Low Signal: DC 0 V ...3 V, High Signal: DC 12 V ... 30 V, input resistance: 2.3 kΩ, PLC
compatible
Sample Times:
Frequency signal: DC 0 to 30 V, 10 mA at DC 24 V, f
Digital outputs (X410A.3), (X410A.4):
Low signal: DC 0 V to 3 V,
High signal: DC 12 V to 30 V, output current: 40 mA, PLC compatible,
Repetition frequency output: frequency signal , F
circuit proof, I
specification EIA485
Analog input (X410A.6):
Analog signal: Input voltage: DC -10 V to 10 V / DC 0 V to 10 V (R
Resolution 13 Bit
Voltage output DC 5 to 12 V for encoder supply (X410A.5):
P = 2 W. Depending on the load on the digital outputs of the frequency inverter
max
and extension module, this value may be lower.
Voltage input DC 24 V for external power supply (X410A.1)
Input voltage range DC 24 V ±10%, U
Rated input current: max. DC 1.0 A (typical DC 0.45 A),
Peak inrush current: typical: < DC 20 A,
External fuse: standard fuse elements for rated current, characteristic: slow,
Safety: Safety extra low voltage (SELV) according to EN 61800-5-1
Conductor cross-section:
The control terminals are suitable for the following cable sizes:
with ferrule:
without ferrule:
16
Technical data of control terminals
1 ms in configurations x40 ("Positioning")
4 ms in all other configurations
= ±60 mA at min. permissible line termination 150 Ω, according to
max
0.25 ... 1.0 mm²
0.14 ... 1.5 mm²
EM-ABS-01 for ACU
= 150 kHz
max
= 150 kHz, overload and short-
max
= DC 30 V,
max
= 100 kΩ),
i
