8.6.1 Absolute value encoder - raw data

For diagnosis, you can check the value transmitted by the absolute value encoder via
parameter
Depending on the encoder technology used, the actual value parameter is built up as
follows:
Hiperface
Position
Binary
EnDat 2.1
Position
Binary
SSI
Additional bits (High) :
Binary
Note:
Note:
SinCos
SinCos encoders do not use absolute values. The actual value parameter remains emp-
ty.

8.6.2 Actual position

Act. position
shows the current actual value (position) in user units [u] in positioning configurations
x40.
