7.4

Baud rate setting/line lengths

The Baud rate settings must be the same in all subscribers. The maximum Baud rate
depends on the necessary total cable length of the system bus. The Baud rate is set
up via parameter
Operation mode
3 - 50 kBaud
4 - 100 kBaud
5 - 125 kBaud
6 - 250 kBaud
7 - 500 kBaud
8 - 1000 kBaud
A baud rate under 50 kBaud, as defined according to CANopen, is not sensible for the
system bus as the data throughput is too low.
The maximum line lengths stated are guidelines.
Depending on the number of subscribers, the baud rate is limited. There are the fol-
lowing restrictions:
Up to and includ-
ing
The bus load must be considered in the projecting phase.
7.5

Setting the node address

A maximum of 63 slaves or frequency inverters with system bus can be operated on
the system bus. Each frequency inverter is given a node ID, which may only exist
once in the system, for its unambiguous identification. The setting of the system bus
node ID is done via the parameter
No.
900 Node-ID
Thus, the system bus possesses a maximum number of 63 subscribers (Network
nodes), plus one frequency inverter as a master.
Note:
46
903 and defines the available cable length.
Baud-Rate
Transmission rate 50 kBaud
Transmission rate 100 kBaud
Transmission rate 125 kBaud
Transmission rate 250 kBaud
Transmission rate 500 kBaud
Transmission rate 1000 kBaud
250 kBit/s:
500 kBit/s:
1000 kBit/s:
Parameters
Description
With the factory setting of parameter
is deactivated for this frequency inverter.
If 900 = 0 is set, the frequency inverter is defined as the mas-
Node-ID
ter. Only one frequency inverter on the system bus may be defined as
the master.
EM-ABS-01 for ACU
Function
not more than 64 subscribers
not more than 28 subscribers
not more than 10 subscribers
900.
Node-ID
Settings
Min. Max.
-1 63
Node-ID
max. line length
1000 meters
800 meters
500 meters
250 meters
100 meters
25 meters
Factory setting
-1
900 = -1, the system bus
03/12
