7.11.3

Timeout monitoring process data channel

Each frequency inverter monitors its received data for whether they are updated
within a defined time window.
The monitoring is done onto the SYNC telegram and the RxPDO channels.
Monitoring SYNC / RxPDOs
No.
939 SYNC timeout
941 RxPDO1 Timeout
942 RxPDO2 Timeout
945 RxPDO3 Timeout
Setting "0" means no timeout monitoring.
Atten-
tion:
If a timeout period is exceeded, the frequency inverter switches to failure mode and
reports one of the faults:
F2200
F2201
F2202
F2203
03/12
Parameters
Description
There is only monitoring for the SYNC telegram if at least one RxPDO or
one TxPDO channel is defined as SYNC controlled.
System bus Timeout SYNC
System bus Timeout RxPDO1
System bus Timeout RxPDO2
System bus Timeout RxPDO3
EM-ABS-01 for ACU
Settings
Min. Max.
0 ms 60000 ms
0 ms 60000 ms
0 ms 60000 ms
0 ms 60000 ms
Factory
setting
0 ms
0 ms
0 ms
0 ms
67
