8.4.15

Act. speed source

The rotary encoder is selected via
er the actual value signal for the speed controller, rotary encoder 2 must be selected as
the source. In the basic setting, rotary encoder 1 is used as the source of actual speed.
Actual speed source
1 - Encoder 1
2 - Encoder 2
3 - Motor model
Note:
8.4.16

Actual position source

In positioning applications (configurations x40), the actual position source must be set.
This is done via
source of the speed control is used as the actual position source.
Actual Position Source
like 766 Actual speed
0 -
source
1 - Encoder 1
2 - Encoder 2
Note:
03/12
Actual Speed Source
766
The actual speed source is speed sensor 1 of the
basic device (factory setting).
The actual speed source is rotary encoder 2 of the
EM-ABS-01 extension module.
The actual speed source is the motor model of the
ACU.
Setting "3-Motor model" is visible and available in configurations 440 and
640 only.
Actual Position Source
1141
The actual speed source is the actual position source
at the same time (factory setting).
The actual position source is speed sensor 1 of the
basic device.
The actual position source is rotary encoder 2 of the
EM-ABS-01 extension module.
In configuration 540,
Actual Speed Source
set to speed encoder 2 (absolute value encoder input of EM-ABS-01).
EM-ABS-01 for ACU
766. If the encoder is to deliv-
Function
1141. In the basic setting, the actual value
Function
766 is not visible and always
