BONFIGLIOLI Active Cube User Manual page 96

Tracks/Protocol
SSI
Gray code SSI, Gray code,
5001
141 kBit/s
SSI, Gray code,
5002
281 kBit/s
SSI, Gray code,
5005
563 kBit/s
SSI, Gray code,
5011
1125 kBit/s
SSI+SINCOS, Gray
5101
code, 141 kBit/s
SSI+SINCOS, Gray
5102
code, 281 kBit/s
SSI+SINCOS, Gray
5105
code, 563 kBit/s
SSI+SINCOS, Gray
5111
code, 1125 kBit/s
SSI+TTL, Gray
5901
code, 141 kBit/s
SSI+TTL, Gray
5902
code, 281 kBit/s
SSI+TTL, Gray
5905
code, 563 kBit/s
SSI+TTL, Gray
5911
code, 1125 kBit/s
SSI
Binary code SSI, binary code,
6001
141 kBit/s
SSI, binary code,
6002
281 kBit/s
SSI, binary code,
6005
563 kBit/s
SSI, binary code,
6011
1125 kBit/s
SSI+SINCOS,
6101 binary code, 141
kBit/s
SSI+SINCOS,
6102 binary code, 281
kBit/s
SSI+SINCOS,
6105 binary code, 563
kBit/s
SSI+SINCOS,
6111 binary code, 1125
kBit/s
SSI+TTL, binary
6901
code, 141 kBit/s
SSI+TTL, binary
6902
code, 281 kBit/s
96
1184
Evaluation of data and clock tracks with the SSI protocol
(without TTL or SinCos track). The data track is transmitted at
140.625 kBaud in Gray code.
ing prepared !
Like 5001. The data track is transmitted at 281.25 kBaud in
Gray code.
Like 5001. The data track is transmitted at 562.5 kBaud in
Gray code.
Like 5001. The data track is transmitted at 1125 kBaud in Gray
code.
Evaluation of Tracks/Protocol A/B as SINCOS track and the
data and clock tracks with the SSI protocol. The data track is
transmitted at 140.625 kBaud in Gray code.
Like 5101. The data track is transmitted at 281.25 kBaud in
Gray code.
Like 5101. The data track is transmitted at 562.5 kBaud in
Gray code.
Like 5101. The data track is transmitted at 1125 kBaud in Gray
code.
Evaluation of Tracks/Protocol A/B as TTL [RS-422] track and
the data and clock tracks with the SSI protocol. The data track
is transmitted at 140.625 kBaud in Gray code.
Like 5901. The data track is transmitted at 281.25 kBaud in
Gray code.
Like 5901. The data track is transmitted at 562.5 kBaud in
Gray code.
Like 5901. The data track is transmitted at 1125 kBaud in Gray
code.
Evaluation of data and clock tracks with the SSI protocol
(without TTL or SinCos track). The data track is transmitted at
140.625 kBaud in binary code.
being prepared !
Like 6001. The data track is transmitted at 281.25 kBaud in
binary code.
Like 6001. The data track is transmitted at 562.25 kBaud in
binary code.
Like 6001. The data track is transmitted at 1125 kBaud in bi-
nary code.
Evaluation of Tracks/Protocol A/B as SINCOS track and the
data and clock tracks with the SSI protocol. The data track is
transmitted at 140.625 kBaud in binary code.
Like 6101. The data track is transmitted at 281.25 kBaud in
binary code.
Like 6101. The data track is transmitted at 562.25 kBaud in
binary code.
Like 6101. The data track is transmitted at 1125 kBaud in bi-
nary code.
Evaluation of Tracks/Protocol A/B as TTL [RS-422] track and
the data and clock tracks with the SSI protocol. The data track
is transmitted at 140.625 kBaud in binary code.
Like 6901. The data track is transmitted at 281.25 kBaud in
binary code.
EM-ABS-01 for ACU
Function
This function is currently be-
This function is currently
03/12
