Error messages and repair
90 EM-ABS-01: Fault correction C/D track.
Error during evaluation of C/D track. Required measuring accuracy not
reached. The offset and amplification error correction for the C/D track
has reached its maximum.
91 EM-ABS-01: No R-track.
Reference truck not found.
− Via parameter
Tracks/Protocol
erence track was selected, but no reference track is connected. If
available, connect the reference track or select another operation
mode.
− The settings of parameter
type-specific division marks of the encoder. Check settings.
− R track defective or cable broken. Check cables and connections.
92 EM-ABS-01: Counting error.
− Encoder evaluation is faulty. Check EMC.
− The settings of parameter
type-specific division marks of the encoder. Check settings.
93 EM-ABS-01: Broken cable.
Collective fault message. At least two of the following errors have oc-
curred:
− F1486 EM-ABS-01 "No sense line"
− F1487 EM-ABS-01 "No A/B track"
− F1489 EM-ABS-01 "No C/D track"
95 EM-ABS-01: Position monitoring.
A non-permissible deviation between the position value of the digital en-
coder interface and the analog A/B track has occurred
01 Dig. encoder: encoder lighting.
Encoder lighting has failed or reached the end of its service life
02 Dig. encoder: Signal amplitude
The amplitude of the signals used for the encoder-internal position calcu-
lation is outside of the permissible range.
03 Dig. encoder: Position value.
The digital position value is incorrect
04 Dig. encoder: Overvoltage.
Encoder supply voltage too high
05 Dig. encoder: Undervoltage.
Encoder supply voltage too low
06 Dig. encoder: Overcurrent
Encoder supply current too high
07 Dig. encoder: battery
Encoder battery is empty or has reached the end of its service life
17 Dig. encoder: Error upon initialization
Initialization of encoder failed. P. 262 contains the code of the error that
occurred during initialization.
18 Dig. encoder: Watchdog reset
A watchdog reset was triggered in the encoder.
19 Dig. encoder: Protocol error
Error in communication with encoder. P. 262 contains the code of the
error that occurred.
20 Dig. encoder: Electronic Typeplate
Error during access to el. type plate. The el. type plate is faulty or not
available. P. 262 contains the code of the error that occurred.
21 Dig. encoder: Overspeed
Error caused by overspeed.
EM-ABS-01 for ACU
1184, an operation mode using a ref-
1183 does not match the
Division marks
1183 does not match the
Division marks
