This operation mode limits the input characteristic to the area between 20% and
100% of the analog signal. If the value for a characteristic point of the X axis is out-
side 0%, it is mapped to the characteristic point (2 V / 0 Hz).
The characteristic point on the X axis is calculated according to the following formula:
-7.60V
(X1=-70% / Y1=-50%)
03/12
Operation mode "21 – unipolar 2-10V/4-20mA"
Kennlinien punkt X = Parameterw
Y
(X2=80% / Y2=85%)
42.50Hz
-25.00Hz
Y
(X2=80% / Y2=85%)
42.50Hz
4.40V
-25.00Hz
(X1=30% / Y1=-50%)
EM-ABS-01 for ACU
ert X ⋅ (100,00%
Point 1:
X1 = [-70.00% · (100.00% - 20.00%)
+ 20.00% ] · 10 V = -7.60 V
Y1 = -50.00% · 50.00 Hz = -25.00 Hz
Point 2:
X2 = [80.00% · (100.00% - 20.00%)
+ 20.00% ] · 10 V = 8.40 V
X
Y2 = 85.00% · 50.00 Hz = 42.50 Hz
8.40V
Tolerance band:
ΔX = [2.00% · (100.00% - 20.00%)
· 10 V] = 0.16 V
The characteristic point 1 has been dis-
placed to the point (2.00V / 0.00 Hz). The
parameter
Tolerance band
taken into account in this example, as no
change of sign of the reference frequency
value takes place.
Point 1:
X1 = [30.00% · (100.00% - 20.00%)
+ 20.00% ] · 10 V = 4.40 V
Y1 = -50.00% · 50.00 Hz = -25.00 Hz
Point 2:
X2 = [80.00% · (100.00% - 20.00%)
+ 20.00% ] · 10 V = 8.40 V
X
Y2 = 85.00% · 50.00 Hz = 42.50 Hz
8.40V
Tolerance band:
ΔX = [2.00% · (100.00% - 20.00%)
· 10 V] = 0.16 V
The direction of rotation is changed in this
example at an analog input signal of 5.88
V, with a tolerance band of ±0.16 V.
- 20,00%) + 20,00%
560 is not
