List of parameters

The parameter list is structured according to the menu branches of the control unit. For
better clarity, the parameters have been marked with pictograms:
The parameter is available in the four data sets.
The parameter value is adjusted by the SETUP routine if a control method for a
synchronous machine is selected for parameter
This parameter cannot be written when the frequency inverter is in operation.
9.1

Actual value menu (VAL)

No.
016 EM Software version
No.
219 Encoder 2 Frequency
220 Encoder 2 Speed
253 Analog Input EM-S1INA
1108 Act. Position
1267 Abs. Encoder Raw Data
1273 Warning Dig. Encoder
1274 Warning Dig. Encoder
Note:
Parameter
Warning Dig. Encoder
and the keypad KP500.
9.2

Parameter menu (PARA)

No.
509 Repetition frequency EM-
S1/S2OUTD
513 EC2 Gear Factor Numerator
514 EC2 Gear Factor Denominator
533 Op. Mode EM-S1OUTD
534 Op. Mode EM-S2OUTD
560 Tolerance band
561 Filter time constant
562 Operation Mode
563 Error/Warning Behaviour
564 Point X1
565 Point Y1
566 Point X2
567 Point Y2
568 Adjustment
118
Frequency inverter data
Description
Actual values of machine
Description
Actual values of frequency inverter
Warning Dig. Encoder
1274 provides a brief description of the information in VPlus
Description
Repetition frequency output
Digital outputs
Digital outputs
Analog input
EM-ABS-01 for ACU
Configuration
Unit Display range
Unit Display range
Hz 0,0 ... 999,99
rpm 0 ... 60000
V -10 ... +10
u Long
String
-
- Word
Selection
-
1273 is intended for read-out via a PLC, parameter
Unit Setting range
- Selection
- -300,00 ... 300,00
- 0,01 ...300,00
- Selection
- Selection
% 0,00 ... 25,00
- Selection
- Selection
- Selection
% -100,00 ... 100,00
% -100,00 ... 100,00
% -100,00 ... 100,00
% -100,00 ... 100,00
- Selection
30.
Chapter
10.2
Chapter
8.6
8.6
8.6
8.6.2
8.6.1
8.4.14
8.4.14
Chapter
8.2.3
8.4.11
8.4.11
8.2.2
8.2.2
8.1.5
8.1.8
8.1.3
8.1.6
8.1.2
8.1.2
8.1.2
8.1.2
8.1.7
