The extension module is assembled simply by plugging on without tools being needed
thanks to the modular set-up of the frequency inverters of the ACU series of devices.
Caution!
The plug-type terminals of the extension module enable economical overall fitting with
a safe function.
Note:
3.1

Restrictions for operation of standard functions

Note:
03/12
Carry out the assembly of the extension module before the frequency
inverter is put into operation, and only in a voltage-free state.
Chapter 10.2 contains a compatibility list of the EM-ABS-01 modules in
combination with the ACU inverter firmware versions.
If an EM-ABS-01 module is used with an ACU device, the following func-
tions of the basic device can no longer be used:
• Repetition frequency mode via MFO1 of base device.
Instead, repetition frequency mode can be realized via digital out-
puts of the EM-ABS-01 module.
• Repetition frequency mode (also PWM frequency input) via digital
inputs of basic device
Instead, the speed sensor 1 input of the basic device can be used.
EM-ABS-01 for ACU 13
