7.12

Control parameters

For the monitoring of the system bus and the display of the internal states, two con-
trol parameters are provided. There is a report of the system bus state and a report
of the CAN state via two actual value parameters.
The
Node State
tional, Stopped state. A PDO transfer is only possible in the Operational state. The
state is controlled by the system bus master (PLC / PC / frequency inverter) via NMT
telegrams.
The
CAN-State
layer. If there are transmission errors, the state changes from OKAY to WARNING
until the cancellation of the communication with BUS-OFF. After BUS-OFF, the CAN
controller is automatically re-initialized and the system bus started again.
Note:
After Bus-OFF, the system bus in the frequency inverter is completely reinitialized.
There is a new boot-up message from the subscriber and an emergency telegram
with the Bus-OFF message is transmitted. The change of state of the subscriber to
Operational is done by the Start-Remote-Node telegram cyclically sent by the system
bus master.
No.
978 Node state
979 CAN state
76
978 parameter gives information about the Pre-Operational, Opera-
979 parameter gives information about the state of the physical
If the BUS-OFF state occurs, the frequency inverter breaks down with
"F2210 BUS-OFF".
Actual values of the system bus
Description
EM-ABS-01 for ACU
Display
1 - Pre-Operational
2 - Operational
3 - Stopped
1 - OKAY
2 - WARNING
3 - BUS-OFF
