Digital outputs EM-S1OUTD and EM-S2OUTD

8.2.1 General

Parameterization of the digital outputs permits a linking to a variety of functions. The
selection of the functions depends on the parameterized configuration.

8.2.2 Operation modes

The operation mode of digital output EM-S1OUTD (Terminal X410A.3) is done via pa-
rameter
Open brake".
The operation mode of digital output EM-S1OUTD (Terminal X410A.4) is done via pa-
rameter
Off".
The operation modes to be selected correspond to the table shown in the operating
instructions of the frequency inverter in the chapter "Digital outputs".

8.2.3 Repetition frequency output via EM-S1OUTD and EM-S2OUTD

Digital outputs EM-S1OUTD and EM-S2OUTD can be used as repetition frequency out-
puts. The output value of the repetition frequency output corresponds to the mechani-
cal frequency of the connected encoder.
Digital outputs EM-S1OUTD and EM-S2OUTD can be set up as a repetition frequency
output via parameter
Repetition frequency EM-S1/2OUTD
0 - Off
1 - On
92
Operation mode EM-S1OUTD
Operation mode EM-S2OUTD
Repetition frequency EM-S1/2OUTD
509
EM-ABS-01 for ACU
533 . By default, this parameter is set to "41 -
534 . By default, this parameter is set to "0 -
509 .
Function
Reference frequency output is turned off.
Factory setting.
The repetition frequency output via digital
outputs EM-S1OUTD and EM-S2OUTD is
turned on. The number of division marks of
the repetition frequency output corresponds
to the number of encoder division marks (set
via 1183 , see chapter 8.4.1).
Division marks
03/12
