8.1.6 Error and warning behavior

The monitoring of the analog input signal necessary according to the application is
configured via the parameter
Error/warning behavior
0 - Off
1 - Warning < 1V/2mA
2 - Shut Down < 1V/2mA
Error switch-off
3 -
< 1V/2mA
Monitoring of the analog input signal is active regardless of the release of the
fre-quency inverter according to the operation mode selected.
In operation mode 2 , the drive mechanism is decelerated according to stopping beha-
vior 1 (stop and shutdown) regardless of the stopping behavior selected (Parameter
Operation mode
Repeat starting of the drive mechanism is possible by switching the start signal on and
off if the error has already been corrected.
Operation mode 3 defines free coasting of the drive, regardless of the stopping beha-
vior selected defined in parameter
Attention! The monitoring of the analog input signal via parameter
90
Error/Warning Behavior
563
The input signal is not monitored.
If the input signal is lower than 1 V, a warning
message is issued.
If the input signal is lower than 1 V, a warning
message is issued; the drive is decelerated ac-
cording to stopping behavior 1.
If the input signal is smaller than 1 V, there is a
warning and fault message and the drive mechan-
ism stops freely.
630 ). If the set holding time has expired, an error message is issued.
Stopping behavior
563 demands examination of the characteristic parameters.
behavior
EM-ABS-01 for ACU
563 .
Function
630 .
Error/Warning
