EPSON AcuLaser CX11/CX11F
FIP-3
Panel Message
ADF Jam
Possible parts that caused the error
1. Edge guide
2. Pick-up roller
Troubleshooting
Step Point to be checked
Is the document skewed because the
1
edge guide is not set along the paper
correctly?
Is the document nonstandard?
2
Are there any paper dust, labels, or
3
foreign materials in the paper path?
Is there any accumulation of paper
4
dust on the Pick-up roller surface of
the ADF?
Does the paper slip when being
5
transferred because the Pick-up
roller of the ADF is worn out?
TROUBLESHOOTING
Yes No
Place the edge guide in Go to Step [2].
the right position.
If possible, place the Go to Step [3].
document not in the
ADF but on the
document glass directly
and start scanning.
Remove the foreign Go to Step [4].
materials.
Clean the roller surface Go to Step [5].
(wipe the roller surface
with soft cloth wrung
out of water).
Replace the Pick-up
roller (p.504)
FIP-4
Panel Message
Service Req C2011
Possible parts that caused the error
1. The cable that connects ADF unit to the scanner main unit.
2. FFC cable
Troubleshooting
Step Point to be checked
Is the cable that connects ADF unit
1
to the scanner main unit
disconnected?
Is the FFC cable disconnected from
2
CN704 connector on the main
board?
Scanner/ADF Section
manuals4you.com manuals4you.com
Revision B
Yes No
Connect the cable Go to Step [2].
correctly.
Connect the cable
correctly.
