EPSON AcuLaser CX11/CX11F
Step Check
Check of image primary transfer process
12
Is the toner image on the drum transferred
normally to IBT BELT?
Execute a test print, turn the power OFF when
you think that the primary transfer process is in
progress during printing, and check the toner
image on IBT BELT.
Check of image secondary transfer process
13
Is the toner image on IBT BELT transferred
normally to the paper?
Execute a test print, turn the power OFF when
you think that the image transfer process is in
progress during printing, and check the paper.
Check after replacement of ESS
14
Replace ESS.
Make a test print of the problem image.
Is the image printed normally?
TROUBLESHOOTING
Yes No
Go to Step [13]. Replace LV/
HVPS. (p.435)
Go to Step [14]. Replace LV/
HVPS. (p.435)
End of procedure Replace "ESS
and possible parts
that caused the
error".
