EPSON AcuLaser CX11/CX11F

1.2.1.6 Reliability

PRINTER SECTION
Paper Jam/ Multi-Feed Rate
Table 1-9. Paper Jam/Multi-sheet Feed Rate (unit: page)
Standard paper
Reliability issue
500-sheet
MPtray
cassette
Jam rate 1/3000 1/5000
Multiple-sheet
1/1500 1/2500
feed rate
Note : The above rates are measured under the following conditions.
Paper size: Regular size
Newly unpackaged paper were used.
The 500-sheet cassette does not support special paper.
Multiple-sheet feed rate: Conditions when adding new paper onto remaining
paper in the tray or cassette are not considered.
MPBF
Main unit: 50,000 pages
NOTE: MIBF: 150,000 pages
Number of images: As color printing uses 4 color images (Y, M, C, K),
four images are counted per page.
For LGL size, 8 images are counted per page.
Calculated as Color : Monochrome = 2 : 1.
Monochrome : 50,000 × 1/3 = 16,700 images
: 50,000 × 2/3 × 4 colors = 133,200 images
Color
MIBF : 16,700 + 133,200 = 149,900 images (approx. 150,000
images)
Mechanical Life
Printer life : 200,000 pages or 5 years, whichever comes first.
500-sheet cassette: 200,000 pages or 5 years, whichever comes first.
Note: Calculated as Color : Monochrome = 2 : 1
Color only : 150,000 pages
Monochrome only: 200,000 pages
Plain paper Special paper
500-sheet 500-sheet
MPtray MPtray
cassette cassette
1/2000 1/3000 1/100
1/1000 1/1500 1/50
Durability
Number of printable pages
Ave. : 3,000 pages/month
Max. : 45,000 pages/month (Monochrome : Color = 3 : 1)

SCANNER SECTION (TBD)

Carriage MCBF
Opening/Closing of the document cover : 30,000 times
Opening/Closing of the scanner module : 2,000 times
---
Light source MTTF
---

ADF SECTION

Feed error
Multi-sheet feed
Paper jam
Life of paper feed
Life of opening/closing operation

SERVICEABILITY

MTTR (Mean Time to Repair)
manuals4you.com manuals4you.com
Revision B
: 100,000 cycles or more
: 10,000 hours
: 1/2,000 or less
: 1/2,000 or less
: 1/1,000 or less
: 100,000 pages
: 15,000 times
: Average 30 minutes or less
(The MTTR is a time for service
personnel to locate and correct the
malfunction only, and the time for
examining malfunction is not
included.)
