EPSON AcuLaser CX11/CX11F
Table 1-5. Scanner Consumption Current
Output voltage Without ADF
5V
(3.3V)

CONSUMPTION CURRENT

When using 500-sheet cassette (option)
5 V/(0.1) A or less
24 V/(0.5) A or less

INRUSH CURRENT

1/2 cycle : 100 A or less (0-peak)
Including heater inrush
(Conditions: 23 degrees C or above, with cold start)

LEAK CURRENT

120V : 3.5mA or less
220V series : 3.5mA or less

GROUND CONDUCTION

When applying 12 V, 30 A to the product's earth terminal and the metallic section
where grounding is required, ground resistance should be 0.1 Ω or less.
FAST TRANSIENT/BURSTS (AC LINE NOISE)
Ensure the following conditions using evaluation methods compliant with IEC61000-
4-4.
1 kV : No errors excluding insignificant dot errors
2 kV : There should be no damaged part
INSTANTANEOUS OUTAGES
No effect on printing quality.
DIP : 1 cycle 100 % (rated voltage -10 %)
With ADF
0.2A 0.2A
0.15A 0.15A
RESISTANCE TO STATIC ELECTRICITY
Ensure the following conditions using evaluation methods compliant with IEC61000-
4-2 CISPR 24.
Contact electric discharge 5 kV
Aerial electric discharge 10 kV
INSULATION RESISTANCE
10 MΩ or more
WITHSTAND VOLTAGE
There should be no break down during application of the voltages shown below.
Leak current should be 20mA or less when applying the voltage for one minute.
Between inlet and non-charged
120V
200V series
manuals4you.com manuals4you.com
: No error on any device after applying
: No error on any device after applying
Table 1-6. Withstand Voltage
Between primary and secondary
metal parts supply transformers
AC1000V AC1500V
AC2000V AC3000V
Revision B
22
