EPSON AcuLaser CX11/CX11F

1.1.4 Controller

New ASIC for controlling scanning and copying, and a FAX controller are added
to the controller for host-based printer.
CPU : TX4955 (192MHz)
RAM : Standard 128 MB (expandable up to 576 MB)
Network I/F board (Cobalt)
Control panel with a large LCD (with backlight)
Built-in Interfaces
USB2.0HS
Ethernet (10Base/100Base-T) (standard or option)
Fax modular (The AcuLaser CX11F only)

1.1.5 Software

ESC/PageS03 installed
A wide variety of copy modes
Copy Mode : Text, Photos, Text/Photos, and High resolution
2 in 1 copy is available
Push-type scan (Enables to send scanned data to another PC via network)
Support both Local TWAIN and Network TWAIN
The ROM is used for all destination models
Network I/F board (Cobalt) compatible
Revision B
19
