Service Data (LT-A750XP/ZK9)
Unit: mm (in)
Item
Starter motor brush length
Starter torque limiter slip torque
Starter relay resistance
Tightening Torque Specifications
Fastening part
Starter motor mounting bolt
Starter motor lead wire mounting nut
Starter motor housing bolt
NOTE
The specified tightening torque is described in the following.
"Starter Motor Components (LT-A750XP/ZK9) (Page 1I-1)"
Reference:
For the tightening torque of fastener not specified in this section, refer to "Tightening Torque List (LT-A750XP/ZK9) in
Section 0C (Page 0C-7)".
Recommended Service Material
Material
Grease
Moly paste
NOTE
Required service material is also described in the following.
"Starter Motor Components (LT-A750XP/ZK9) (Page 1I-1)"
Special Tool
09900–20102
Vernier calipers (200 mm)
)(Page 1I-3)
Specifications
Standard
Limit
Standard
Special Tools and Equipment
SUZUKI recommended product or Specification
SUZUKI SUPER GREASE "A" or
equivalent
SUZUKI Moly paste or equivalent
Specification
12.0 (0.47)
6.5 (0.26)
41.2 – 62.8 N˜m
(4.2 – 6.4 kgf-m, 14.5 – 32.5 lbf-ft)
3 – 5 :
Tightening torque
N˜m kgf-m
10 1.0
6 0.6
5 0.5
P/No.: 99000–25010
P/No.: 99000–25140
09900–25008
Multi circuit tester set
)(Page 1I-4)
Starting System:
B931G41907002
Note
B931G41907003
Note
lbf-ft
)(Page 1I-2)
7.0
)(Page 1I-2)
4.5
)(Page 1I-3)
3.5
B931G41908001
Note
)(Page 1I-2) / )(Page 1I-2)
)(Page 1I-3)
B931G41908002
