This manual contains an introductory description on the SUZUKI LT-A500XP/Z and procedures for its inspection/

service and overhaul of its main components.

Other information considered as generally known is not included.

Read the GENERAL INFORMATION section to familiarize yourself with the vehicle and its maintenance. Use this

section as well as other sections to use as a guide for proper inspection and service.

This manual will help you know the vehicle better so that you can assure your customers of fast and reliable ser-

vice.

* This manual has been prepared on the basis of the latest specifications at the time of publication. If modifi-

cations have been made since then, differences may exist between the content of this manual and the

actual vehicle.

* Illustrations in this manual are used to show the basic principles of operation and work procedures. They

may not represent the actual vehicle exactly in detail.

* This manual is written for persons who have enough knowledge, skills and tools, including special tools, for

servicing SUZUKI vehicles. If you do not have the proper knowledge and tools, ask your authorized

SUZUKI motorcycle dealer to help you.

WARNING

Inexperienced mechanics or mechanics without the proper tools and equipment may not be able to

properly perform the services described in this manual.

Improper repair may result in injury to the mechanic and may render the vehicle unsafe for the rider.

FOREWORD

Table of Contents

Chapters

Table of Contents

Troubleshooting

Need help?

Do you have a question about the kq500 and is the answer not in the manual?

Questions and answers

Normand Sylvain

April 13, 2025

en dessou pompe a eau a i a til un tube a collecter

Summary of Contents for Suzuki kq500

Page 1 * This manual is written for persons who have enough knowledge, skills and tools, including special tools, for servicing SUZUKI vehicles. If you do not have the proper knowledge and tools, ask your authorized SUZUKI motorcycle dealer to help you.
Page 3: Table Of Contents
TABLE OF CONTENTS Precautions............... 00-i Body and Accessories..........9-i Precautions .............. 9-1 Precautions ............00-1 Wiring Systems ............9A-1 General Information ........... 0-i Lighting Systems ............9B-1 General Information ..........0A-1 Combination Meter / Fuel Meter / Horn ....9C-1 Maintenance and Lubrication ......... 0B-1 Exterior Parts ............9D-1 Service Data............0C-1 Body Structure ............9E-1...
Page 5: Precautions
Table of Contents 00- i Section 00 Precautions CONTENTS Precautions ..........00-1 General Precautions ........... 00-1 Precautions for Electrical Circuit Service .... 00-2 Precautions............00-1 Warning / Caution / Note........00-1...
Page 6: Exhaust System
CAUTION Indicates a potential hazard that could result • If parts replacement is necessary, replace in death or injury. the parts with Suzuki Genuine Parts or their equivalent. CAUTION • When removing parts that are to be reused, keep them arranged in an orderly manner...
Page 7 Precautions: 00-2 • Never reuse a circlip. When installing a • Inspect each terminal for corrosion and new circlip, take care not to expand the contamination. The terminals must be clean and free end gap larger than required to slip the of any foreign material which could impede proper circlip over the shaft.
Page 8 00-3 Precautions: • When connecting meter probe from the terminal side Fuse of the coupler (where connection from harness side • When a fuse blows, always investigate the cause to not being possible), use extra care not to force and correct it and then replace the fuse.
Page 9 Precautions: 00-4 • Be careful not to touch the electrical terminals of the • The EPS control unit and EPS body assembly cannot electronic parts (ECM, etc.). The static electricity from be disassembled. Replace the whole unit with a new your body may damage these.
Page 10 00-5 Precautions: • Before measuring voltage at each terminal, check to When checking system circuits including an electronic make sure that battery voltage is 11 V or higher. control unit such as ECM, etc., it is important to perform Terminal voltage check with a low battery voltage will careful check, starting with items which are easier to lead to erroneous diagnosis.
Page 11 Precautions: 00-6 4) Using continuity inspect or voltage check procedure Voltage check as described below, inspect the wire harness If voltage is supplied to the circuit being checked, voltage terminals for open circuit and poor connection. check can be used as circuit check. Locate abnormality, if any.
Page 12 “A” “D”: To other parts “D” “B” Using The Multi-Circuit Testers • Use the Suzuki multi-circuit tester set. • Use well-charged batteries in the tester. “C” • Be sure to set the tester to the correct testing range. Special tool (A): 09900–25008 (Multi-circuit tester set)
Page 13 Precautions: 00-8 Using the testers NOTE • Incorrectly connecting the (+) and (–) probes may • When connecting the multi-circuit tester, cause the inside of the tester to be burnout. use the needle pointed probe to the back • If the voltage and current are not known, make side of the lead wire coupler and connect measurements using the highest range.
Page 14 00-9 Precautions:...
Page 15: Maintenance And Lubrication
Symbols .............. 0A-1 Front Differential Gear Oil Replacement ...0B-11 Abbreviations ............0A-1 Final Gear Oil Inspection........0B-12 SAE-to-Former SUZUKI Term ......0A-2 Final Gear Oil Replacement......0B-12 Vehicle Side View ..........0A-3 Throttle Cable Play Inspection and Vehicle Identification Number ......0A-3 Adjustment ............0B-13...
Page 16: General Information
Apply oil. Use engine oil unless otherwise specified. Apply molybdenum oil solution. (Mixture of engine oil and SUZUKl MOLY PASTE in a ratio of 1:1). Apply SUZUKI SUPER GREASE “A” or equivalent. 99000-25010 Apply SUZUKI MOLY PASTE or equivalent. 99000-25140 Apply WATER RESISTANCE GREASE.
Page 17 J1930 terms and abbreviations which may be used in (TPS) this manual in compliance with SAE recommendations, as well as their former SUZUKI names. Voltage Regulator (VR): Voltage Regulator Ex. SAE term (Abbreviation): Former SUZUKI term Air Cleaner (ACL): Air Cleaner, Air Cleaner Box...
Page 18 PERFORMANCE 4 MOTOR OIL or an equivalent engine oil. Use of SF/SG or SH/SJ in API with MA in JASO. Suzuki recommends the use of SAE 10W-40 engine oil. If SAE 10W-40 engine oil is not available, select and alternative according to the chart.
Page 19 Use of SF/SG or SH/SJ in API with MA in JASO. aluminum radiator, mixed with distilled water only. Suzuki recommends the use of SAE 10W-40 engine oil. If SAE 10W-40 engine oil is not available, select an Water for mixing alternative according to the chart.
Page 20 0A-5 General Information: Country and Area Codes B931H20101009 The following codes stand for the applicable country(-ies) and area(-s). Code Country or Area Effective Frame No. LT-A500XPK9 (P-17) Sweden LT-A500XPK9 (P-24) Australia LT-A500XPK9 (P-28) Canada LT-A500XPK9 (P-33) U.S.A. 5SAAM45P97100001 – LT-A500XPZK9 (P-17) Sweden LT-A500XPZK9 (P-24) Australia...
Page 21 General Information: 0A-6 Warning, Caution and Information Labels Location B931H20101011 12, 13 1, 20, 21 22, 23 15, 16 17, 18 2, 26, 27 I931H1010010-03 1. Certification plate (English) For P-24, 33 15. Front carrier warning label (English) For P-24, 33 2.
Page 22 0A-7 General Information: Component Location Electrical Components Location B931H20103001 I931H1010005-03 1. Battery 7. Drive relay 13. Ignition switch 2. Starter relay/Main fuse 8. Mode select switch coupler 14. Power source 3. Fuse box 9. Starter motor 15. Ignition coil 4. Neutral relay 10.
Page 23 General Information: 0A-8 I931H1010006-05 19. Cooling fan thermo-switch 26. Parking/rear brake switch 33. Speed sensor 20. Resister 27. Regulator/Rectifier 34. CKP sensor 21. 4WD/Diff-lock actuator diode 28. Parking brake relay 35. Generator 22. Neutral relay diode 29. Diff-lock relay 36. EPS control unit 23.
Page 24: Fuel System
0A-9 General Information: Specifications Specifications B931H20107001 NOTE These specifications are subject to change without notice. Dimensions and dry mass Item Specification Remark 2 115 mm (83.3 in) P-28, 33 Overall length 2 165 mm (85.2 in) P-17, 24 1 210 mm (47.6 in) P-28, 33 Overall width 1 250 mm (49.2 in)
Page 25: Front Suspension
General Information: 0A-10 Chassis Item Specification Remark Front suspension Independent, double wishbone, coil spring, oil damped Rear suspension Independent, double wishbone, coil spring, oil damped Front wheel travel 170 mm (6.7 in) Rear wheel travel 195 mm (7.7 in) Caster 3.7°...
Page 26 09900–22302 09900–22403 09900–25008 09900–25009 Plastigauge Plastigauge Small bore gauge (18 Multi circuit tester set Needle pointed probe – 35 mm) 09900–26006 09904–41010 09910–32812 09910–32820 09912–34510 Engine tachometer SUZUKI Diagnostic Crankshaft installer Crankshaft installer Cylinder disassembly system set attachment ring tool...
Page 27 General Information: 0A-12 09913–10750 09913–50121 09913–60910 09913–61510 09913–70210 Compression gauge Oil seal remover Bearing and gear Bearing puller Bearing installer set adapter puller (10 – 75) 09913–75520 09915–40620 09915–64512 09915–74511 09915–74521 Bearing installing tool Oil filter wrench Compression gauge Oil pressure gauge Adapter hose (600 kPa) 09915–74533...
Page 28 0A-13 General Information: 09920–33540 09920–53740 09921–20240 09921–21910 09922–31430 Clutch shoe remover Clutch sleeve hub Bearing remover set Bearing holder set Clutch spring holder compressor 09923–73210 09923–74511 09924–41830 09924–52420 09924–52450 Bearing remover Bearing remover Bearing retainer Secondary bevel gear Fixed driven face wrench (50 mm) holder holder...
Page 29 General Information: 0A-14 09930–82720 09940–40211 09940–40220 09940–92430 09941–34513 Mode selection switch Fuel pressure gauge Fuel pressure gauge Rear axle nut wrench Bearing installer adapter attachment (36×36 mm) 09941–51012 09941–53610 09942–72410 09942–83110 09943–88211 Ring locknut wrench Front fork oil seal Tie-rod end remover Clip remover Pinion bearing installer hammer...
Page 30: Maintenance And Lubrication
0B-1 Maintenance and Lubrication: Maintenance and Lubrication General Information Precautions Precautions for Maintenance B931H20200001 The “Periodic Maintenance Schedule Chart” lists the recommended intervals for all the required periodic service work necessary to keep the vehicle operating at peak performance and economy. Maintenance intervals are expressed in terms of kilometers, miles and months for your convenience.
Page 31 Maintenance and Lubrication: 0B-2 Interval Initial 200 Every 1 000 Every 2 000 Item miles Initial 100 Every 600 Every 1 200 months Initial 1 Every 3 Every 6 — Brake fluid Replace every 2 years. — — Brake hose Replace every 4 years.
Page 32 0B-3 Maintenance and Lubrication: Repair Instructions Air Cleaner Element Inspection and Cleaning 3) Carefully use compressed air to clean the air cleaner B931H20206001 element. Inspect and clean element CAUTION Every 1 000 km (600 miles, 3 months) Always apply compressed air to the inside of Inspection the air cleaner element.
Page 33 Maintenance and Lubrication: 0B-4 Exhaust Pipe Bolt and Muffler Bolt Inspection Valve Clearance Inspection and Adjustment B931H20206002 B931H20206003 Tighten exhaust pipe bolts, muffler bolt and nut Inspect valve clearance Initially at 200 km (100 miles, 1 month) and every 1 Initially at 200 km (100 miles, 1 month) and every 2 000 km (600 miles, 3 months) thereafter 000 km (1 200 miles, 6 months) thereafter...
Page 34 0B-5 Maintenance and Lubrication: 5) Remove the spark plug cap and spark plug. Refer to 9) Insert the thickness gauge to check the clearance “Spark Plug Cap and Spark Plug Removal and between the valve stem end and the adjusting screw Installation: in Section 1H”.
Page 35 O-rings and install the inspection caps (1). Replace spark plug Every 6 000 km (4 000 miles) : Grease 99000–25010 (SUZUKI SUPER GREASE A or equivalent) Refer to “Spark Plug Cap and Spark Plug Removal and Installation: in Section 1H”.
Page 36 0B-7 Maintenance and Lubrication: Spark Plug Gap Spark Arrester Cleaning B931H20206006 1) Remove the spark plug. Refer to “Spark Plug Cap Spark arrester cleaning and Spark Plug Removal and Installation: in Every 2 000 km (1 200 miles, 6 months) Section 1H”.
Page 37 Maintenance and Lubrication: 0B-8 4) Tighten the muffler end cover nut (3) to the specified 4) Inspect the fuel feed hose for damage and fuel torque. leakage. If any defects are found, the fuel feed hose must be replaced. Tightening torque Muffler end cover nut (a): 11 N·m (1.1 kgf-m, 8.0 lbf-ft) I931H1020015-01...
Page 38 0B-9 Maintenance and Lubrication: Engine Oil Replacement 5) Pour new oil through the oil filler. When performing an oil change (without oil filter replacement), the 1) Place the vehicle on a level ground and set the brake engine will hold about 2.3 L (2.4/2.0 US/lmp qt) of oil. lock.
Page 39 Also, do not use a genuine Suzuki automobile oil filter on this vehicle. 5) Install a new oil filter. Turn it by hand until you feel that the oil filter O-ring contacts the oil filter mounting surface.
Page 40 0B-11 Maintenance and Lubrication: 3) Tighten the oil level plug (1) and oil filler plug (2) to 4) Tighten the oil drain plug (1) to the specified torque. the specified torque. CAUTION CAUTION Replace the gasket washers with a new one. Replace the gasket washers with new ones.
Page 41 Maintenance and Lubrication: 0B-12 Final Gear Oil Inspection 4) Drain oil by removing the oil drain plug (1) and oil B931H20206011 filler plug (2). Inspect final gear oil Every 2 000 km (1 200 miles, 6 months) 1) Place the vehicle on a level ground. 2) Remove the filler plug (1), and inspect the oil level.
Page 42 0B-13 Maintenance and Lubrication: Throttle Cable Play Inspection and Adjustment Cooling System Inspection B931H20206013 B931H20206015 Inspect throttle cable play Replace engine coolant Initially at 200 km (100 miles, 1 month) and every 1 Every 2 years 000 km (600 miles, 3 months) thereafter Engine Coolant Level Inspection Inspect and adjust the throttle cable play “a”...
Page 43 Maintenance and Lubrication: 0B-14 3) Remove the left inner fender. Refer to “Front Side 8) Pour the specified engine coolant up to the radiator Exterior Parts Removal and Installation: in inlet. Section 9D”. Engine coolant capacity (including reservoir) 4) Remove the front under cover. Refer to “Under 2 450 ml (2.6/2.2 US/lmp qt) Cover Removal and Installation: in Section 9D”.
Page 44 0B-15 Maintenance and Lubrication: Radiator Hoses Inspection Drive V-belt Inspection and Replacement B931H20206016 Inspect radiator hoses Inspect drive V-belt Every 2 000 km (1 200 miles, 6 months) Every 1 000 km (600 miles, 3 months) Inspect the radiator hoses for damage and engine Replace drive V-belt coolant leakage.
Page 45 Maintenance and Lubrication: 0B-16 Drive Shaft Boots Inspection Brake Fluid Level Check B931H20206017 Inspect brake fluid level Inspect drive shaft Every 1 000 km (600 miles, 3 months) Initially at 200 km (100 miles, 1 month) and every 1 1) Place the vehicle on a level ground. 000 km (600 miles, 3 months) thereafter 2) Check the brake fluid level by observing the lower •...
Page 46 0B-17 Maintenance and Lubrication: Front Brake Pads Check Front Brake Hose Replacement The extent of front brake pad wear can be checked by Replace brake hose observing the grooved limit line “A” on the pad. When the Every 4 years wear exceeds the grooved limit line, replace the pads with new ones.
Page 47 Maintenance and Lubrication: 0B-18 Brake Pedal Free Travel Rear Brake (Parking Brake) Lever Play Adjustment Inspection 1) After adjusting the brake pedal, check the rear brake Inspect and adjust the rear brake pedal free travel “a” as lever play “a”. The brake lever play “a” as measured follows.
Page 48 0B-19 Maintenance and Lubrication: 5) After adjusting the play, check that the rear wheels roll freely without applying the brake, the “a” transmission in neutral and the rear wheels off the ground. Readjust the rear brake lever if the rear wheels could not roll freely.
Page 49 Maintenance and Lubrication: 0B-20 Steering System Inspection Toe Adjustment B931H20206022 B931H20206023 Adjust the toe-out as follows: Inspect steering system 1) Loosen the lock-nuts (1), (2) on each tie-rod. Initially at 200 km (100 miles, 1 month) and every 1 000 km (600 miles, 3 months) thereafter CAUTION Steering should be adjusted properly for smooth turning •...
Page 50 0B-21 Maintenance and Lubrication: 5) After adjustment has been made, tighten the four lock-nuts to the specified torque. Tightening torque Tie-rod lock-nut (a): 29 N·m (2.9 kgf-m, 21.0 lbf- I931H1020059-01 Handlebar holder nut 60 N⋅m (6.0 kgf-m, 43.5 lbf-ft) I831G1020089-01 Suspensions Inspection B931H20206024 Inspect suspension...
Page 51 Maintenance and Lubrication: 0B-22 I931H1020060-02 I931H1020062-04 Steering shaft lower nut 162 N⋅m (16.2 kgf-m, 117.0 lbf-ft) Front suspension arm pivot nut (Upper) 60 N⋅m (6.0 kgf-m, 43.5 lbf-ft) Tie-rod end nut 29 N⋅m (2.9 kgf-m, 21.0 lbf-ft) Front suspension arm pivot nut (Lower) 65 N⋅m (6.5 kgf-m, 47.0 lbf-ft) I931H1020082-01 Steering shaft upper nut 120 N⋅m (12.0 kgf-m, 87.0 lbf-ft)
Page 52 0B-23 Maintenance and Lubrication: I931H1020065-04 I931H1020068-04 Tie-rod end nut 29 N⋅m (2.9 kgf-m, 21.0 lbf-ft) Footrest mounting bolt (M8) 26 N⋅m (2.6 kgf-m, 19.0 lbf-ft) Steering knuckle end nut (Upper and Lower) 29 N⋅m (2.9 kgf-m, Footrest mounting bolt (M10) 55 N⋅m (5.5 kgf-m, 40.0 lbf-ft) 21.0 lbf-ft) I931H1020069-03 I931H1020066-04...
Page 53 Maintenance and Lubrication: 0B-24 I931H1020072-03 I931H1020075-02 Rear brake case bolt 26 N⋅m (2.6 kgf-m, 19.0 lbf-ft) Rear stabilizer joint nut 60 N⋅m (6.0 kgf-m, 43.5 lbf-ft) Rear brake cam lever nut 11 N⋅m (1.1 kgf-m, 8.0 lbf-ft) I931H1020076-02 I931H1020073-02 Trailer towing mounting bolt 60 N⋅m (6.0 kgf-m, 43.5 lbf-ft) Rear shock absorber mounting nut (Upper and Lower) 60 N⋅m (6.0 kgf-m, 43.5 lbf-ft) Rear suspension arm pivot nut (Upper and Lower) 60 N⋅m (6.0...
Page 54: Rear Brakes
0B-25 Maintenance and Lubrication: Compression Pressure Check 4) Start the engine. B931H20206026 5) Shift the range lever to the “High” position. Refer to “Compression Pressure Check: in Section 6) Slowly open the throttle and note the engine speed 1D”. (r/min) when the vehicle begins to move forward. Oil Pressure Check Engagement speed B931H20206027...
Page 55 For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List: in Section 0C”. Special Tools and Equipment Recommended Service Material B931H20208001 Material SUZUKI recommended product or Specification Note Brake fluid DOT 4 — (Page 0B-16)
Page 56 0B-27 Maintenance and Lubrication: Special Tool B931H20208002 09900–20803 09900–20805 Thickness gauge Tire depth gauge (Page 0B-5) / (Page 0B- (Page 0B-19) 09900–25008 09900–26006 Multi circuit tester set Engine tachometer (Page 0B-25) (Page 0B-25) / (Page 0B-25) 09915–40620 09917–14910 Oil filter wrench Tappet adjust driver (Page 0B-10) / (Page 0B-5)
Page 57: Service Data
Service Data: 0C-1 Service Data General Information Specifications Service Data B931H20307001 Valve + Valve Guide Unit: mm (in) Item Standard Limit 30.6 (1.20) — Valve diam. 27.0 (1.06) — 0.05 – 0.10 (0.002 – 0.004) — Valve clearance (When cold) 0.17 –...
Page 58 0C-2 Service Data: Cylinder + Piston + Piston Ring Unit: mm (in) Item Standard Limit Compression pressure Approx. 1 000 kPa (10.0 kgf/cm , 142 psi) — (Automatic-decomp. actuated) Piston-to-cylinder clearance 0.030 – 0.040 (0.0012 – 0.0016) 0.120 (0.0047) Nicks or Cylinder bore 87.500 –...
Page 59 Service Data: 0C-3 Drive Train Unit: mm (in) Except ratio Item Standard Limit Automatic transmission ratio Variable change (2.902 – 0.779) — Secondary reduction ratio 2.733 (41/19 x 19/15) — Front 3.600 (36/10) — Final reduction ratio Rear 3.600 (36/10) —...
Page 60 0C-4 Service Data: Injector + Fuel Pump + Fuel Pressure Regulator Item Specification Note 11 – 13 Ω at 20 °C (68 °F) Injector resistance Fuel pump discharge amount 55.5 ml (1.88/1.95 US/lmp qt) and more/10 sec. Fuel pressure regulator operating Approx.
Page 61 Service Data: 0C-5 Electrical Unit: mm (in) Item Standard/Specification Note NGK: CR6E Type Spark plug DENSO: U20ESR-N 0.7 – 0.8 (0.028 – 0.031) Spark performance Over 8 (0.3) at 1 atm. Terminal – 0.1 – 0.6 Ω Primary Ground Ignition coil resistance Plug cap –...
Page 62 0C-6 Service Data: Brake + Wheel Unit: mm (in) Item Standard/Specification Limit Rear brake pedal height 12.5 – 22.5 (0.5 – 0.9) — Rear brake pedal free travel 20 – 30 (0.8 – 1.2) — Front brake disc thickness 3.3 – 3.7 (0.13 – 0.15) 3.0 (0.20) Front brake disc runout —...
Page 63 Service Data: 0C-7 Tightening Torque List B931H20307002 Engine Item N⋅m kgf-m lbf-ft Spark plug Air cleaner box mounting bolt 0.45 Cylinder head cover bolt Rocket arm shaft bolt 20.0 Intake pipe bolt Cylinder head bolt (M8) 18.0 Initial 18.0 Cylinder head bolt (M10) Final 27.0 Cylinder head base nut...
Page 64 0C-8 Service Data: Drive Train Item N⋅m kgf-m lbf-ft 4WD/Diff-lock actuator mounting bolt Front drive (differential) gear case cover bolt Front drive (differential) gear case mounting nut 36.0 Front differential gear oil level plug 0.81 Front differential gear oil filler plug 25.5 Front differential gear oil drain plug 23.0...
Page 65 Service Data: 0C-9 Chassis Item N⋅m kgf-m lbf-ft Handlebar upper clamp bolt 19.0 Handlebar holder nut 43.5 Rear brake lever holder clamp bolt Throttle lever case clamp bolt Throttle lever case screw EPS body assembly mounting bolt 19.0 EPS body assembly mounting nut 20.0 Steering shaft upper nut 87.0...
Page 66 0C-10 Service Data: Tightening Torque Chart For other bolts and nuts not listed in the preceding page, refer to this chart: Bolt Diameter Conventional or “4” marked bolt “7” marked bolt “a” (mm) N⋅m kgf-m lbf-ft N⋅m kgf-m lbf-ft 0.15 0.23 0.45 0.55...
Page 67: Engine General Information And Diagnosis
Table of Contents 1- i Section 1 Engine CONTENTS Precautions ..........1-1 DTC “C40” (P0505-H/L): ISC Valve Circuit Malfunction............1A-62 Precautions............. 1-1 DTC “C41” (P230-H/L): FP Relay Circuit Precautions for Engine.......... 1-1 Malfunction............1A-68 Engine General Information and Specifications .............1A-70 Service Data............1A-70 Diagnosis ..........1A-1 Special Tools and Equipment ......1A-71 General Description ..........1A-1 Special Tool ............1A-71...
Page 68: Engine Mechanical
1-ii Table of Contents Engine Mechanical ........1D-1 Special Tools and Equipment ......1D-70 Recommended Service Material .......1D-70 Schematic and Routing Diagram......1D-1 Special Tool ............1D-70 Throttle Cable Routing Diagram......1D-1 Diagnostic Information and Procedures....1D-2 Engine Lubrication System ....1E-1 Engine Mechanical Symptom Diagnosis.....1D-2 Precautions............1E-1 Compression Pressure Check ......1D-2 Precautions for Engine Oil ........1E-1...
Page 69: Ignition System
Table of Contents 1-iii Thermostat Inspection ........1F-11 Repair Instructions ..........1H-3 Water Pump Components......... 1F-12 Spark Plug Cap and Spark Plug Removal and Water Pump Removal and Installation....1F-12 Installation ............1H-3 Water Pump Disassembly and Assembly ..1F-13 Spark Plug Inspection and Cleaning ....1H-3 Water Pump Related Parts Inspection ....
Page 70: Charging System
1-iv Table of Contents Charging System ........1J-1 Specifications ............. 1J-12 Service Data............1J-12 Schematic and Routing Diagram......1J-1 Tightening Torque Specifications...... 1J-13 Charging System Diagram ........1J-1 Special Tools and Equipment ......1J-13 Component Location ........... 1J-1 Recommended Service Material ....... 1J-13 Charging System Components Location.....
Page 71: Precautions
Precautions: Precautions Engine Precautions Precautions for Engine B931H21000001 Refer to “General Precautions: in Section 00” and “Precautions for Electrical Circuit Service: in Section 00”.
Page 72: Engine General Information And Diagnosis
1A-1 Engine General Information and Diagnosis: Engine General Information and Diagnosis Engine General Description Injection Timing Description B931H21101001 Injection Time (Injection Volume) The factors to determine the injection time include the basic fuel injection time, which is calculated on the basis of the intake air pressure, engine speed and throttle opening angle, and various compensations.
Page 73 Engine General Information and Diagnosis: 1A-2 Injection Stop Control Signal Descriptions When the vehicle tips over, the tip-over sensor sends a signal to TIP-OVER SENSOR SIGNAL (FUEL SHUT-OFF) the ECM. Then, this signal cuts OFF current supplied to the fuel pump, fuel injectors and ignition coils.
Page 74 1A-3 Engine General Information and Diagnosis: Dealer Mode The defective function is memorized in the computer. Use the special tool’s coupler to connect to the mode select switch. The memorized malfunction code is displayed on LCD (DISPLAY) panel. Malfunction means that the ECM does not receive signal from the devices.
Page 75: Schematic And Routing Diagram
Engine General Information and Diagnosis: 1A-4 Schematic and Routing Diagram FI System Wiring Diagram B931H21102001 I931H1110005-03...
Page 76: Terminal Alignment Of Ecm Coupler
1A-5 Engine General Information and Diagnosis: Terminal Alignment of ECM Coupler B931H21102002 I931H1110006-01 TERMINAL NO. CIRCUIT TERMINAL NO. CIRCUIT Ignition coil (IG1) CKP sensor signal (CKP-) Fuel injector (#1) Fuel pump relay (FP relay) Power source (+B) Power source for fuel injector Power source for back-up (BATT) Diff-lock relay (DL relay) Brake switch (BRK)
Page 77: Component Location
