Suzuki kq750 Service Manual page 602

Chassis
Handlebar clamp bolt
Handlebar holder nut
Rear brake lever holder clamp bolt
Throttle lever case bolt
Steering shaft upper nut
Steering shaft bolt
EPS control unit mounting nut
EPS body assembly mounting bolt
EPS body assembly mounting nut
Steering shaft lower nut
Front suspension arm pivot nut (Upper)
Front suspension arm pivot nut (Lower)
Steering knuckle end nut (Upper and Lower)
Tie-rod end nut
Tie-rod lock-nut
Front shock absorber mounting bolt (Upper)
Front shock absorber mounting nut (Lower)
Front wheel hub nut
Rear wheel hub nut
Wheel set nut (Front and Rear)
Front brake hose union bolt
Front brake air bleeder valve
Front brake pad mounting pin
Front brake caliper mounting bolt
Caliper holder pin
Caliper holder slide pin
Brake pipe flare nut
Front brake disc mounting bolt
Brake master cylinder mounting bolt
Footrest mounting bolt (M8)
Footrest mounting bolt (M10)
Rear stabilizer joint nut
Rear shock absorber mounting nut (Upper and Lower)
Rear suspension arm pivot nut (Upper and Lower)
Rear knuckle end nut (Upper and Lower)
Rear brake cam lever nut
Rear brake case bolt
Rear brake pedal shaft nut
Rear brake pedal screw
Trailer towing bolt
Brake lever pivot bolt and nut
Brake lever pivot bolt lock-nut
Front propeller shaft boot clamp screw
Rear propeller shaft boot clamp screw
Item N˜m kgf-m
26 2.6
60 6.0
10 1.0
2 0.2
120 12.0
26 2.6
12 1.2
26 2.6
28 2.8
162 16.2
60 6.0
65 6.5
29 2.9
29 2.9
29 2.9
55 5.5
60 6.0
110 11.0
121 12.1
60 6.0
23 2.3
6 0.6
17 1.7
26 2.6
18 1.8
23 2.3
16 1.6
23 2.3
10 1.0
26 2.6
55 5.5
60 6.0
60 6.0
60 6.0
60 6.0
11 1.1
26 2.6
60 6.0
4.5 0.45
60 6.0
6 0.6
6 0.6
1.3 0.13
2 0.2
Service Data: 0C-9
lbf-ft
19.0
43.5
7.0
1.5
87.0
19.0
8.5
19.0
20.0
117.0
43.5
47.0
21.0
21.0
21.0
40.0
43.5
79.5
87.5
43.5
16.5
4.5
12.5
19.0
13.0
16.5
11.5
16.5
7.0
19.0
40.0
43.5
43.5
43.5
43.5
8.0
19.0
43.5
3.0
43.5
4.5
4.5
1.0
1.5
