0C-6 Service Data:
Brake + Wheel
Unit: mm (in)
Item
Rear brake pedal height
Rear brake pedal free travel
Front brake disc thickness
Front brake disc runout
Front master cylinder bore
Front master cylinder piston diam.
Front brake caliper cylinder bore
Front brake caliper piston diam.
Rear brake lever play
Brake fluid type
Steering angle
Turning radius
Toe-out (With 75 kg, 165 lbs)
Camber
Caster
Tire
Unit: mm (in)
Item
Cold inflation tire pressure
(Solo riding)
Tire size
Tire tread depth
Suspension
Unit: mm (in)
Item
Front shock absorber spring
adjustor
Rear shock absorber spring adjustor
Fuel + Oil
Item
Fuel type
Fuel tank capacity
Engine oil type
Engine oil capacity
Standard/Specification
12.5 – 22.5 (0.5 – 0.9)
20 – 30 (0.8 – 1.2)
12.700 – 12.743 (0.5000 – 0.5017)
12.657 – 12.684 (0.4983 – 0.4994)
33.960 – 34.010 (1.3370 – 1.3390)
33.878 – 33.928 (1.3338 – 1.3357)
6 – 8 (0.2 – 0.3)
46q (right & left)
3.1 m (10.2 ft)
5 r 4 mm (0.20 r 0.16)
Front 35 kPa (0.35 kgf/cm
Rear 30 kPa (0.30 kgf/cm
AT25 x 8-12 œœ, tubeless
Front
AT25 x 10-12 œœ, tubeless
Rear
Front
Rear
Specification
Use only unleaded gasoline of at least 87 pump octane (R/2
+ M/2) or 91 octane or higher rated by the Research
Method. Gasoline containing MTBE (Methyl Tertiary Butyl
Ether), less than 10% ethanol, or less than 5% methanol
with appropriate cosolvents and corrosion inhibitor is
permissible.
Gasoline used should be graded 91 octane or higher.
An unleaded gasoline type is recommended.
17.5 L (4.6/3.8 US/lmp gal)
SAE 10 W-40, API SF/SG or SH/SJ with JASO MA
Change
Filter change
Overhaul
—
—
DOT 4
–1.3q
3.3q
Standard
2
, 5.1 psi)
2
, 4.4 psi)
—
—
Standard
2/5 position
2/5 position
2 300 ml (2.4/2.0 US/lmp qt)
2 500 ml (2.6/2.2 US/lmp qt)
3 000 ml (3.2/2.6 US/lmp qt)
Limit
—
—
3.0 (0.20)
0.30 (0.012)
—
—
—
—
—
—
—
—
—
—
—
Limit
—
—
—
—
4.0 (0.16)
4.0 (0.16)
Limit
—
—
Note
P-28, 33
Others
