18. Cooling fan thermo-switch
19. Resister
20. 4WD/Diff-lock actuator diode
21. Neutral relay diode
22. Cooling fan
23. Handlebar switch
23
25
34
24. Parking brake switch
25. Brake lever switch
26. Regulator/Rectifier
27. Parking brake relay
28. Diff-lock relay
29. Actuator
General Information:
31
30
24
33
32
30. High position diode
31. Low position diode
32. Speed sensor
33. CKP sensor
34. Generator
