Parameter
num —— The value of Global TPID. It must be 4 Hex integers. By default, it is
8100.
Command Mode
Global Configuration Mode
Example
Configure Global TPID of the VLAN-VPN as 0x9100:
TL-SL5428E(config)#dot1q-tunnel tpid 9100

dot1q-tunnel mapping

Description
The dot1q-tunnel mapping command is used to add the VLAN Mapping entry.
To delete the VLAN Mapping entry, please use the no dot1q-tunnel mapping
command.
Syntax
dot1q-tunnel mapping c-vlan sp-vlan [descript]
no dot1q-tunnel mapping c-vlan
Parameter
c-vlan —— Customer VLAN ID, ranging from 1 to 4094.
sp-vlan —— Service Provider VLAN ID, ranging from 1 to 4094.
descript —— Give a description to the VLAN Mapping entry, which contains 15
characters at most.
Command Mode
Global Configuration Mode
Example
Add a VLAN Mapping entry named "TP" with the C-VLAN being 2 and the
SP-VLAN being 10:
TL-SL5428E(config)#dot1q-tunnel mapping 2 10 TP
