Syntax
rule rule-id {deny | permit} [ [smac source-mac] smask source-mac-mask ]
[ [dmac destination-mac] dmask destination-mac-mask ] [vid vlan-id] [type
ethernet-type] [pri user-pri] [tseg time-segment]
no rule rule-id
Parameter
rule-id —— The rule ID.
deny —— The operation to discard packets.
permit ——The operation to forward packets. By default, it is "permit".
source-mac —— The source MAC address contained in the rule.
source-mac-mask —— The source MAC address mask. It is required if you
typed the source MAC address.
destination-mac —— The destination MAC address contained in the rule.
destination-mac-mask —— The destination MAC address mask. It is required
if you typed the destination MAC address.
vlan-id —— The VLAN ID contained in the rule, ranging from 1 to 4094.
ethernet-type —— EtherType contained in the rule, in the format of 4-hex
number.
user-pri —— The user priority contained in the rule, ranging from 0 to 7. By
default, it is not limited.
time-segment —— The time-range for the rule to take effect. By default, it is
not limited.
Command Mode
Mac Access-list Configuration Mode
Example
Create a MAC ACL whose ID is 20, and add Rule 10 for it. In the rule, the source
MAC address is 00:01:3F:48:16:23, the source MAC address mask is
11:11:11:11:11:00, VLAN ID is 2, the user priority is 5, the time-range for the rule
to take effect is tSeg1, and the packets match this rule will be forwarded by the
switch:
TL-SL5428E(config)#mac access-list 20
TL-SL5428E(config-mac-acl)#rule 10 permit smac 00:01:3F:48:16:23 smask
11:11:11:11:11:00 vid 2 pri 5 tseg tSeg1
