Chapter 5
Protocol VLAN (Virtual Local Area Network) is the way to classify VLANs based on Protocols. A
Protocol is relative to a single VLAN ID. The untagged packets and the priority-tagged packets
matching the protocol template will be tagged with this VLAN ID.

protocol-vlan template

Description
The protocol-vlan template command is used to create Protocol-based VLAN
template. To delete Protocol-based VLAN template, please use no
protocol-vlan template command.
Syntax
protocol-vlan template name protocol-name ether-type type
no protocol-vlan template template-idx
Parameter
protocol-name —— Give a name for the Protocol-based VLAN Template ,
which contains 8 characters at most.
type —— Enter the Ethernet protocol type field in the protocol template,
composing of 4 Hex integers.
template-idx —— The number of the Protocol-based VLAN Template. You can
get the template corresponding to the number by the
template
Command Mode
Global Configuration Mode
Example
Create a Protocol-based VLAN template named "TP" whose Ethernet protocol
type is 0x2024:
TL-SL5428E(config)#protocol-vlan template name TP ether-type 2024
TL-SL5428E
Protocol-based VLAN Commands
command.
JetStream L2 Managed Switch CLI Guide
36
show protocol-vlan
