Page 1 TL-SL5428E 24-Port 10/100Mbps + 4-Port Gigabit JetStream L2 Managed Switch REV1.3.0 1910010737...
Page 2: Fcc Statement
COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.
Page 3 afety Information  When product has power button, the power button is one of the way to shut off the product; When there is no power button, the only way to completely shut off power is to disconnect the product or the power adapter from the power source. ...
Page 4: Table Of Contents
CONTENTS Package Contents ..........................1 Chapter 1 About this Guide......................2 Intended Readers ......................2 Conventions........................2 Overview of This Guide ....................2 Chapter 2 Introduction ........................6 Overview of the Switch ....................6 Main Features.......................6 Appearance Description ....................7 2.3.1 Front Panel ......................7 2.3.2 Rear Panel ......................8 Chapter 3 Login to the Switch.......................9 Login..........................9 Configuration ........................9...
Page 5 5.1.1 Port Config .......................29 5.1.2 Port Mirror ......................30 5.1.3 Port Security ....................31 5.1.4 Port Isolation ....................33 5.1.5 Loopback Detection ..................33 LAG ..........................35 5.2.1 LAG Table ......................36 5.2.2 Static LAG ......................37 5.2.3 LACP Config ....................38 Traffic Monitor ......................40 5.3.1 Traffic Summary....................40 5.3.2 Traffic Statistics ....................41 MAC Address......................42...
Page 6 6.9.1 PVLAN Config....................76 6.9.2 Port Config .......................77 6.10 Application Example for Private VLAN................79 Chapter 7 Spanning Tree ......................81 STP Config .........................85 7.1.1 STP Config.......................85 7.1.2 STP Summary....................87 Port Config........................88 MSTP Instance ......................90 7.3.1 Region Config ....................90 7.3.2 Instance Config ....................90 7.3.3 Instance Port Config..................92 STP Security.......................93...
Page 7 9.2.1 Rate Limit.......................124 9.2.2 Storm Control ....................125 Voice VLAN ......................127 9.3.1 Global Config ....................129 9.3.2 Port Config .....................129 9.3.3 OUI Config .....................131 Chapter 10 ACL ..........................133 10.1 Time-Range ......................133 10.1.1 Time-Range Summary ...................133 10.1.2 Time-Range Create..................134 10.1.3 Holiday Config....................135 10.2 ACL Config .......................135 10.2.1 ACL Summary....................135...
Page 8 11.4 DoS Defend ......................164 11.4.1 DoS Defend....................166 11.4.2 DoS Detect....................166 11.5 802.1X ........................167 11.5.1 Global Config ....................171 11.5.2 Port Config .....................172 11.5.3 Radius Server ....................174 Chapter 12 SNMP........................176 12.1 SNMP Config ......................178 12.1.1 Global Config ....................178 12.1.2 SNMP View ....................179 12.1.3 SNMP Group....................179 12.1.4...
Page 9 14.3.1 Cluster Summary ...................209 14.3.2 Cluster Config ....................211 14.3.3 Member Config ....................214 14.3.4 Cluster Topology ....................215 14.4 Application Example for Cluster Function ..............217 Chapter 15 Maintenance ......................219 15.1 System Monitor......................219 15.1.1 CPU Monitor ....................219 15.1.2 Memory Monitor .....................220 15.2 Log..........................220 15.2.1 Log Table .......................221...
Page 10: Package Contents
One console cable  Two mounting brackets and other fittings  Installation Guide  Resource CD for TL-SL5428E switch, including:  This User Guide  Other Helpful Information Note: Make sure that the package contains the above items. If any of the listed items are damaged or...
Page 11: Chapter 1 About This Guide
Chapter 1 About this Guide This User Guide contains information for setup and management of TL-SL5428E switch. Please read this guide carefully before operation. 1.1 Intended Readers This Guide is intended for network managers familiar with IT concepts and network terminologies.
Page 12 Chapter Introduction Chapter 4 System This module is used to configure system properties of the switch. Here mainly introduces: System Info: Configure the description, system time and  network parameters of the switch. User Management: Configure the user name and password for ...
Page 13 Chapter Introduction Chapter 8 Multicast This module is used to configure multicast function of the switch. Here mainly introduces: IGMP Snooping: Configure global parameters of IGMP  Snooping function, port properties, VLAN and multicast VLAN. Multicast IP: Configure multicast IP table. ...
Page 14 Chapter Introduction Chapter 12 SNMP This module is used to configure SNMP function to provide a management frame to monitor and maintain the network devices. Here mainly introduces: SNMP Config: Configure global settings of SNMP function.  Notification: Configure notification function ...
Page 15: Chapter 2 Introduction
Chapter 2 Introduction Thanks for choosing the TL-SL5428E 24-Port 10/100Mbps + 4-Port Gigabit JetStream L2 Managed Switch! 2.1 Overview of the Switch Designed for workgroups and departments, TL-SL5428E from TP-LINK provides wire-speed performance and full set of layer 2 management features. It provides a variety of service features and multiple powerful functions with high security.
Page 16: Appearance Description
 Manageability + IP Clustering provides high scalability and easy Single-IP-Management. + Supports Telnet, CLI, SNMP v1/v2c/v3, RMON and web access. + Port Mirroring enables monitoring selected ingress/egress traffic. 2.3 Appearance Description 2.3.1 Front Panel Figure 2-1 Front Panel The following parts are located on the front panel of the switch: ...
Page 17: Rear Panel
2.3.2 Rear Panel The rear panel of TL-SL5428E features a power socket and a Grounding Terminal (marked with ). Figure 2-2 Rear Panel  Grounding Terminal: TL-SL5428E already comes with Lightning Protection Mechanism. You can also ground the switch through the PE (Protecting Earth) cable of AC cord or with Ground Cable.
Page 18: Chapter 3 Login To The Switch
Chapter 3 Login to the Switch 3.1 Login 1) To access the configuration utility, open a web-browser and type in the default address http://192.168.0.1 in the address field of the browser, then press the Enter key. Figure 3-1 Web-browser Tips: To log in to the switch, the IP address of your PC should be set in the same subnet addresses of the switch.
Page 19 Figure 3-3 Main Setup-Menu Note: Clicking Apply can only make the new configurations effective before the switch is rebooted. If you want to keep the configurations effective even the switch is rebooted, please click Save Config. You are suggested to click Save Config before cutting off the power or rebooting the switch to avoid losing the new configurations.
Page 20: Chapter 4 System
Chapter 4 System The System module is mainly for system configuration of the switch, including four submenus: System Info, User Management, System Tools and Access Security. 4.1 System Info The System Info, mainly for basic properties configuration, can be implemented on System Summary, Device Description, System Time, Daylight Saving Time and System IP pages.
Page 21 Indicates the 1000Mbps port is at the speed of 10Mbps or 100Mbps. Indicates the SFP port is not connected to a device. Indicates the SFP port is at the speed of 1000Mbps. Indicates the SFP port is at the speed of 100Mbps. When the cursor moves on the port, the detailed information of the port will be displayed.
Page 22: Device Description
4.1.2 Device Description On this page you can configure the description of the switch, including device name, device location and system contact. Choose the menu System→System Info→Device Description to load the following page. Figure 4-4 Device Description The following entries are displayed on this screen: Device Description ...
Page 23: Daylight Saving Time
The following entries are displayed on this screen: Time Info  Current System Date: Displays the current date and time of the switch. Current Time Source: Displays the current time source of the switch. Time Config  Manual: When this option is selected, you can set the date and time manually.
Page 24: System Ip
The following entries are displayed on this screen: DST Config  DST Status: Enable or Disable DST. Predefined Mode: Select a predefined DST configuration:  USA: First Sunday in April, 02:00 ~ Last Sunday in October, 02:00.  Australia: First Sunday in October, 02:00 ~ First Sunday in April, 03:00.
Page 25 Figure 4-7 System IP The following entries are displayed on this screen: IP Config  MAC Address: Displays MAC Address of the switch. IP Address Mode: Select the mode to obtain IP Address for the switch. Static IP: When this option is selected, you should enter IP ...
Page 26: User Management
4.2 User Management User Management functions to configure the user name and password for users to log on to the Web management page with a certain access level so as to protect the settings of the switch from being randomly changed. The User Management function can be implemented on User Table and User Config pages.
Page 27: System Tools
Access Level: Select the access level to login. Admin: Admin can edit, modify and view all the settings of  different functions. Guest: Guest only can view the settings without the right to  edit and modify. User Status: Select Enable/Disable the user configuration. Password: Type a password for users’...
Page 28: Config Backup
The following entries are displayed on this screen: Config Restore  Restore Config: Click the Restore Config button to restore the backup configuration file. It will take effect after the switch automatically reboots. Note: It will take a few minutes to restore the configuration. Please wait without any operation. To avoid any damage, please don’t power down the switch while being restored.
Page 29: System Reboot
Figure 4-12 Firmware Upgrade Note: Don’t interrupt the upgrade. Please select the proper software version matching with your hardware to upgrade. To avoid damage, please don't turn off the device while upgrading. After upgrading, the device will reboot automatically. You are suggested to backup the configuration before upgrading. 4.3.4 System Reboot On this page you can reboot the switch and return to the login page.
Page 30: Access Security
Figure 4-14 System Reset Note: After the system is reset, the switch will be reset to the default and all the settings will be cleared. 4.4 Access Security Access Security provides different security measures for the remote login so as to enhance the configuration management security.
Page 31: Ssl Config
The following entries are displayed on this screen: Access Control Config  Control Mode: Select the control mode for users to log on to the Web management page. IP-based: Select this option to limit the IP-range of the users  for login.
Page 32 default the switch has a certificate (self-signed certificate) and a corresponding private key. The Certificate/Key Download function enables the user to replace the default key pair. After SSL is effective, you can log on to the Web management page via https://192.168.0.1. For the first time you use HTTPS connection to log into the switch with the default certificate, you will be prompted that “The security certificate presented by this website was not issued by a trusted certificate authority”...
Page 33: Ssh Config
4.4.3 SSH Config As stipulated by IFTF (Internet Engineering Task Force), SSH (Secure Shell) is a security protocol established on application and transport layers. SSH-encrypted-connection is similar to a telnet connection, but essentially the old telnet remote management method is not safe, because the password and data transmitted with plain-text can be easily intercepted.
Page 34 Max Connect: Specify the maximum number of the connections to the SSH server. No new connection will be established when the number of the connections reaches the maximum number you set. The default value is 5. Key Download  Key Type: Select the type of SSH Key to download.
Page 35 2. Click the Open button in the above figure to log on to the switch. Enter the login user name and password, and then you can continue to configure the switch. Application Example 2 for SSH: Network Requirements  1. Log on to the switch via password authentication using SSH and the SSH function is enabled on the switch.
Page 36 3. On the Web management page of the switch, download the public key file saved in the computer to the switch. Note: The key type should accord with the type of the key file. The SSH key downloading can not be interrupted. 4.
Page 37 5. After the public key and private key are downloaded, please log on to the interface of PuTTY and enter the IP address for login. After successful authentication, please enter the login user name. If you log on to the switch without entering password, it indicates that the key has been successfully downloaded.
Page 38: Chapter 5 Switching
Chapter 5 Switching Switching module is used to configure the basic functions of the switch, including four submenus: Port, LAG, Traffic Monitor and MAC Address. 5.1 Port The Port function, allowing you to configure the basic features for the port, is implemented on the Port Config, Port Mirror, Port Security, Port Isolation and Loopback Detection pages.
Page 39: Port Mirror
Status: Allows you to Enable/Disable the port. When Enable is selected, the port can forward the packets normally. Speed and Duplex: Select the Speed and Duplex mode for the port. The device connected to the switch should be in the same Speed and Duplex mode with the switch.
Page 40: Port Security
The following entries are displayed on this screen. Mirroring Port  Mirroring Port: Select a port from the pull-down list as the mirroring port. When disable is selected, the Port Mirror feature will be disabled. Mirrored Port  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered.
Page 41 Figure 5-3 Port Security The following entries are displayed on this screen: Port Security  Select: Select the desired port for Port Security configuration. It is multi-optional. Port: Displays the port number. Max Learned MAC: Specify the maximum number of MAC addresses that can be learned on the port.
Page 42: Port Isolation
5.1.4 Port Isolation Port Isolation provides a method of restricting traffic flow to improve the network security by forbidding the port to forward packets to the ports that are not on its forward portlist. Choose the menu Switching→Port→Port Isolation to load the following page. Figure 5-4 Port Isolation Config The following entries are displayed on this screen: Port Isolation Config...
Page 43 Choose the menu Switching→Port→LoopbackDetection to load the following page. Figure 5-5 Loopback Detection Config The following entries are displayed on this screen: Global Config  LoopbackDetection Here you can enable or disable Loopback Detection function Status: globally. Detection Interval: Set a Loopback Detection interval between 1 and 1000 seconds. By default, it’s 30 seconds.
Page 44: Lag
Select: Select the desired port for Loopback Detection configuration. It is multi-optional. Port: Displays the port number. Status: Enable or disable Loopback Detection function for the port. Operation Mode: Select the mode how the switch processes the detected loops.  Alert: When a loop is detected, display an alert.
Page 45: Lag Table
Tips: Calculate the bandwidth for a LAG: If a LAG consists of the four ports in the speed of 1000Mbps Full Duplex, the whole bandwidth of the LAG is up to 8000Mbps (2000Mbps * 4) because the bandwidth of each member port is 2000Mbps counting the up-linked speed of 1000Mbps and the down-linked speed of 1000Mbps.
Page 46: Static Lag
Operation: Allows you to view or modify the information for each LAG.  Edit: Click to modify the settings of the LAG.  Detail: Click to get the information of the LAG. Click the Detail button for the detailed information of your selected LAG. Figure 5-7 Detail Information 5.2.2 Static LAG On this page, you can manually configure the LAG.
Page 47: Lacp Config
Description: Give a description to the LAG for identification. LAG Table  Member Port: Select the port as the LAG member. Clearing all the ports of the LAG will delete this LAG. Tips: The LAG can be deleted by clearing its all member ports. A port can only be added to a LAG.
Page 48 Figure 5-9 LACP Config The following entries are displayed on this screen: Global Config  System Priority: Specify the system priority for the switch. The system priority and MAC address constitute the system identification (ID). A lower system priority value indicates a higher system priority. When exchanging information between systems, the system with higher priority determines which link aggregation a link belongs to, and the system with lower priority adds the proper links to the link aggregation...
Page 49: Traffic Monitor
Status: Enable/Disable the LACP feature for your selected port. LAG: Displays the LAG number which the port belongs to. 5.3 Traffic Monitor The Traffic Monitor function, monitoring the traffic of each port, is implemented on the Traffic Summary and Traffic Statistics pages. 5.3.1 Traffic Summary Traffic Summary screen displays the traffic information of each port, which facilitates you to monitor the traffic and analyze the network abnormity.
Page 50: Traffic Statistics
Packets Rx: Displays the number of packets received on the port. The error packets are not counted in. Packets Tx: Displays the number of packets transmitted on the port. Octets Rx: Displays the number of octets received on the port. The error octets are counted in.
Page 51: Mac Address
Received: Displays the details of the packets received on the port. Sent: Displays the details of the packets transmitted on the port. Broadcast: Displays the number of good broadcast packets received or transmitted on the port. The error frames are not counted in. Multicast: Displays the number of good multicast packets received or transmitted on the port.
Page 52: Address Table
Being kept after reboot Relationship between bound Type Configuration Way Aging out (if the configuration is address and the port saved) Static Manually configuring bound Address Table address can not be learned by the other ports same VLAN. Dynamic Automatically bound Address Table learning...
Page 53: Static Address
Type: Select the type of your desired entry. All: This option allows the address table to display all the  address entries. Static: This option allows the address table to display the static  address entries only. Dynamic: This option allows the address table to display the ...
Page 54: Dynamic Address
The following entries are displayed on this screen: Create Static Address  MAC Address: Enter the static MAC Address to be bound. VLAN ID: Enter the corresponding VLAN ID of the MAC address. Port: Select a port from the pull-down list to be bound. Search Option ...
Page 55 On this page, you can configure the dynamic MAC address entry. Choose the menu Switching→MAC Address→Dynamic Address to load the following page. Figure 5-14 Dynamic Address The following entries are displayed on this screen: Aging Config  Auto Aging: Allows you to Enable/Disable the Auto Aging feature. Aging Time: Enter the Aging Time for the dynamic address.
Page 56: Filtering Address
Bind: Click the Bind button to bind the MAC address of your selected entry to the corresponding port statically. Tips: Setting aging time properly helps implement effective MAC address aging. The aging time that is too long or too short results decreases the performance of the switch. If the aging time is too long, excessive invalid MAC address entries maintained by the switch may fill up the MAC address table.
Page 57 Filtering Address Table  Select: Select the entry to delete the corresponding filtering address. It is multi-optional. MAC Address: Displays the filtering MAC Address. VLAN ID: Displays the corresponding VLAN ID. Port: Here the symbol “__” indicates no specified port. Type: Displays the Type of the MAC address.
Page 58: Chapter 6 Vlan
Chapter 6 VLAN The traditional Ethernet is a data network communication technology basing on CSMA/CD (Carrier Sense Multiple Access/Collision Detect) via shared communication medium. Through the traditional Ethernet, the overfull hosts in LAN will result in serious collision, flooding broadcasts, poor performance or even breakdown of the Internet.
Page 59: Q Vlan
6.1 802.1Q VLAN VLAN tags in the packets are necessary for the switch to identify packets of different VLANs. The switch works at the data link layer in OSI model and it can identify the data link layer encapsulation of the packet only, so you can add the VLAN tag field into the data link layer encapsulation for identification.
Page 60: Vlan Config
PVID  PVID (Port Vlan ID) is the default VID of the port. When the switch receives an un-VLAN-tagged packet, it will add a VLAN tag to the packet according to the PVID of its received port and forward the packets. When creating VLANs, the PVID of each port, indicating the default VLAN to which the port belongs, is an important parameter with the following two purposes: （1）...
Page 61 To ensure the normal communication of the factory switch, the default VLAN of all ports is set to VLAN1. The following entries are displayed on this screen: VLAN Table  Click the Select button to quick-select the corresponding entry VLAN ID Select： based on the VLAN ID number you entered.
Page 62: Port Config
VLAN ID: Enter the ID number of VLAN. Description: Give a description to the VLAN for identification. Check: Click the Check button to check whether the VLAN ID you entered is valid or not. VLAN Members  Port Select: Click the Select button to quick-select the corresponding entry based on the port number you entered.
Page 63 VLAN Port Config  Port Select: Click the Select button to quick-select the corresponding entry based on the port number you entered. Select the desired port for configuration. It is multi-optional. Select: Displays the port number. Port: Select the Link Type from the pull-down list for the port. Link Type: ...
Page 64: Mac Vlan
Configuration Procedure: Step Operation Description Set the link type for Required. On the VLAN→802.1Q VLAN→Port Config page, set port. the link type for the port basing on its connected device. Create VLAN. Required. On the VLAN→802.1Q VLAN→VLAN Config page, click the Create button to create a VLAN. Enter the VLAN ID and the description for the VLAN.
Page 65: Port Enable
Figure 6-7 Create and View MAC VLAN The following entries are displayed on this screen: VLAN Table  MAC Address: Enter the MAC address. Description: Give a description to the MAC address for identification. VLAN ID: Enter the ID number of the MAC VLAN. This VLAN should be one of the 802.1Q VLANs the ingress port belongs to.
Page 66: Protocol Vlan
Figure 6-8 Enable MAC VLAN for Port Select your desired port for VLAN Mapping function. All the ports are disabled for VLAN Mapping function by default. Configuration Procedure: Step Operation Description Set the link type for Required. On the VLAN→802.1Q VLAN→Port Config page, set port.
Page 67: Protocol Vlan
The packet in Protocol VLAN is processed in the following way: When receiving an untagged packet, the switch matches the packet with the current Protocol VLAN. If the packet is matched, the switch will add a corresponding Protocol VLAN tag to it. If no Protocol VLAN is matched, the switch will add a tag to the packet according to the PVID of the received port.
Page 68: Protocol Template
6.3.2 Protocol Template The Protocol Template should be created before configuring the Protocol VLAN. By default, the switch has defined the IP Template, ARP Template, RARP Template, etc. You can add more Protocol Template on this page. Choose the menu VLAN→Protocol VLAN→Protocol Template to load the following page. Figure 6-10 Create and View Protocol Template The following entries are displayed on this screen: Create Protocol Template...
Page 69: Application Example For 802.1Q Vlan
Figure 6-11 Enable Protocol VLAN for Port Select your desired port for VLAN Mapping function. All the ports are disabled for VLAN Mapping function by default. Configuration Procedure: Step Operation Description Set the link type for port. Required. On the VLAN→802.1Q VLAN→Port Config page, set the link type for the port basing on its connected device.
Page 70: Application Example For Mac Vlan
PCs in the two VLANs cannot communicate with each other.  Network Diagram  Configuration Procedure  Configure switch A  Step Operation Description Configure Required. On VLAN→802.1Q VLAN→Port Config page, configure Link Type of the the link type of Port 2, Port 3 and Port 4 as ACCESS, TRUNK and ports ACCESS respectively Create VLAN10...
Page 71 The two departments are in VLAN10 and VLAN20 respectively. The two notebooks can just  access the server of their own departments, that is, Server A and Server B, in the two meeting rooms; The MAC address of Notebook A is 00-19-56-8A-4C-71, Notebook B’s MAC address is ...
Page 72: Application Example For Protocol Vlan
Configure Switch B  Step Operation Description Configure Required. On VLAN→802.1Q VLAN→Port Config page, configure the Link Type of the link type of Port 21 and Port 22 as GENERAL and TRUNK respectively. ports Create VLAN10 Required. On VLAN→802.1Q VLAN→VLAN Config page, create a VLAN with its VLANID as 10, owning Port 21 and Port 22, and configure the egress rule of Port 21 as Untag.
Page 73 Network Diagram  Configuration Procedure  Configure Switch A  Step Operation Description Configure Required. On VLAN→802.1Q VLAN→Port Config page, configure the Link Type of the link type of Port 11 and Port 13 as ACCESS, and configure the link type ports of Port 12 as GENERAL.
Page 74: Vlan Vpn
Step Operation Description Port Enable Required. On the VLAN→Protocol VLAN→Port Enable page, select and enable Port 3, Port 4 and Port 5 for Protocol VLAN feature. Create Protocol On VLAN→Protocol VLAN→Protocol VLAN page, create protocol VLAN 10 VLAN 10 with Protocol as IP. Create Protocol On VLAN→Protocol VLAN→Protocol VLAN page, create protocol VLAN 20...
Page 75: Vpn Config
This VLAN VPN function is implemented on the VPN Config, VLAN Mapping and Port Enable pages. 6.7.1 VPN Config This page allows you to enable the VPN function, adjust the global TPID for VLAN-VPN packets and enable the VPN up-link port. When VPN mode is enabled, the switch will add a tag to the received tagged packet basing on the VLAN mapping entries.
Page 76: Port Enable
Figure 6-13 Create VLAN Mapping Entry The following entries are displayed on this screen: VLAN Mapping Config  C VLAN: Enter the ID number of the Customer VLAN. C VLAN refers to the VLAN to which the packet received by switch belongs. SP VLAN: Enter the ID number of the Service Provider VLAN.
Page 77 Figure 6-14 Enable VLAN Mapping for Port Select your desired port for VLAN Mapping function. All the ports are disabled for VLAN Mapping function by default. Note: When VPN mode is globally enabled, VPN function takes effect on all ports. If VPN mode is disabled, VLAN Mapping function can be enabled by selecting your desired port on this Port Enable page.
Page 78: Gvrp
Create (Service Optional. On the VLAN→802.1Q VLAN page, create the Provider) VLAN SP VLAN. For the steps of creating VLAN, please refer to 802.1Q VLAN. 6.8 GVRP GVRP (GARP VLAN Registration Protocol) is an implementation of GARP (generic attribute registration protocol). GVRP allows the switch to automatically add or remove the VLANs via the dynamic VLAN registration information and propagate the local VLAN registration information to other switches, without having to individually configure each VLAN.
Page 79  LeaveAll Timer: Once a GARP entity starts up, it starts the LeaveAll timer, and sends out a LeaveAll message after the timer times out, so that other GARP entities can re-register all the attribute information on this entity. After that, the entity restarts the LeaveAll timer to begin a new cycle.
Page 80 Figure 6-15 GVRP Config Note: If the GVRP feature is enabled for a member port of LAG, please ensure all the member ports of this LAG are set to be in the same status and registration mode. The following entries are displayed on this screen: Global Config ...
Page 81: Private Vlan
LeaveAll Timer: Once the LeaveAll Timer is set, the port with GVRP enabled can send a LeaveAll message after the timer times out, so that other GARP ports can re-register all the attribute information. After that, the LeaveAll timer will start to begin a new cycle. The LeaveAll Timer ranges from 1000 to 30000 centiseconds.
Page 82 Private VLAN technology is mainly used in campus or enterprise networks to achieve user layer-2-separation and to save VLAN resources of uplink devices.  The Elements of a Private VLAN Primary VLAN: A Private VLAN has one Primary VLAN and one Secondary VLAN. Primary VLAN is the user VLAN uplink device can identify but it is not the actual VLAN the end user is in.
Page 83 2) Port configuration and MAC address duplication should be synchronized on the switch. Port configuration synchronization is completed in the whole configuration progress and MAC address duplication is implemented while FDB is changing.  Port configuration synchronization: when configuring promiscuous and host ports for a Private VLAN, the system will automatically add the promiscuous port and the host port synchronously to the corresponding Primary VLAN and Secondary VLAN.
Page 84  MAC address duplication: After port configuration synchronization, packets from Secondary VLAN can be forwarded via the promiscuous port untagged, and those from Primary VLAN can be sent via the host port untagged. In order for these packets can be forwarded in unicast via the right port, MAC address duplication is used to expand the VLANs the MAC address is in.
Page 85: Pvlan Config
The Private VLAN packet forwarding process (here we take traffic transmission for PC2) based on the figure above is illustrated as follows: PC2 sends out its first upstream packet with the source MAC as mac_2 and the destination MAC as mac_a. This packet is untagged. When the host port Port2 on the switch receives this packet, it adds a default VLAN ID 2 to this packet and learns its source MAC address.
Page 86: Port Config
Figure 6-17 Create Private VLAN The following entries are displayed on this screen: Create Private VLAN  Primary VLAN: Enter the ID number of the Primary VLAN. Secondary VLAN: Enter the ID number of the Secondary VLAN. Search Option  Search Option: Select a Search Option from the pull-down list and click the Search button to find your desired entry in Private VLAN.
Page 87: Configuration Procedure
Figure 6-18 Create and View Protocol Template The following entries are displayed on this screen: Port Config  Port: Select the desired port for configuration. Port Type: Select the Port Type from the pull-down list for the port. Primary VLAN: Specify the Primary VLAN the port belongs to.
Page 88: Application Example For Private Vlan
Delete VLAN. Optional. On the VLAN→Private VLAN→PVLAN page, select the desired entry to delete the corresponding VLAN by clicking the Delete button. 6.10 Application Example for Private VLAN Network Requirements  Switch A is connecting to Switch B, Switch B is connecting to Switch C; ...
Page 89 Step Operation Description Required. On the VLAN→Private VLAN→Port Configure page, Promiscuous configure the port type of Port3 and Port4 as Promiscuous, enter port to Private Primary VLAN 6 and Secondary VLAN 2-3, and click the Add button. VLANs Add Host port to Required.
Page 90: Chapter 7 Spanning Tree
Chapter 7 Spanning Tree STP (Spanning Tree Protocol), subject to IEEE 802.1D standard, is to disbranch a ring network in the Data Link layer in a local network. Devices running STP discover loops in the network and block ports by exchanging information, in that way, a ring network can be disbranched to form a tree-topological ring-free network to prevent packets from being duplicated and forwarded endlessly in the network.
Page 91 Figure 7-1 Basic STP diagram STP Timers  Hello Time: Hello Time ranges from 1 to 10 seconds. It specifies the interval to send BPDU packets. It is used to test the links. Max. Age: Max. Age ranges from 6 to 40 seconds. It specifies the maximum time the switch can wait without receiving a BPDU before attempting to reconfigure.
Page 92 Step Operation If the priority of the BPDU received on the port is lower than that of the BPDU if of the port itself, the switch discards the BPDU and does not change the BPDU of the port. If the priority of the BPDU is higher than that of the BPDU of the port itself, the switch replaces the BPDU of the port with the received one and compares it with those of other ports on the switch to obtain the one with the highest priority.
Page 93 point-to-point link, it can transit to forwarding state after getting response from the downstream switch through handshake. RSTP Elements  Edge Port: Indicates the port connected directly to terminals. P2P Link: Indicates the link between two switches directly connected. MSTP (Multiple Spanning Tree Protocol), compatible with both STP and RSTP and subject to IEEE 802.1s standard, not only enables spanning trees to converge rapidly, but also enables packets of different VLANs to be forwarded along their respective paths so as to provide redundant links with a better load-balancing mechanism.
Page 94: Stp Config
Port States  In an MSTP, ports can be in the following four states:  Forwarding: In this status the port can receive/forward data, receive/send BPDU packets as well as learn MAC address.  Learning: In this status the port can receive/send BPDU packets and learn MAC address. ...
Page 95 Figure 7-4 STP Config The following entries are displayed on this screen: Global Config  STP: Select Enable/Disable STP function globally on the switch. Version: Select the desired STP version on the switch.  STP: Spanning Tree Protocol.  RSTP: Rapid Spanning Tree Protocol. ...
Page 96: Stp Summary
Note: The forward delay parameter and the network diameter are correlated. A too small forward delay parameter may result in temporary loops. A too large forward delay may cause a network unable to resume the normal state in time. The default value is recommended. An adequate hello time parameter can enable the switch to discover the link failures occurred in the network without occupying too much network resources.
Page 97: Port Config
Figure 7-5 STP Summary 7.2 Port Config On this page you can configure the parameters of the ports for CIST Choose the menu Spanning Tree→Port Config to load the following page. Figure 7-6 Port Config The following entries are displayed on this screen: Port Config ...
Page 98 Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select the desired port for STP configuration. It is multi-optional. Port: Displays the port number of the switch. Status: Select Enable /Disable STP function for the desired port. Priority: Enter a value from 0 to 240 divisible by 16.
Page 99: Mstp Instance
Note: Configure the ports connected directly to terminals as edge ports and enable the BPDU protection function as well. This not only enables these ports to transit to forwarding state rapidly but also secures your network. All the links of ports in a LAG can be configured as point-to-point links. When the link of a port is configured as a point-to-point link, the spanning tree instances owning this port are configured as point-to-point links.
Page 100 Figure 7-8 Instance Config The following entries are displayed on this screen: Instance Table  Instance ID Select: Click the Select button to quick-select the corresponding Instance ID based on the ID number you entered. Select: Select the desired Instance ID for configuration. It is multi-optional. Instance: Displays Instance ID of the switch.
Page 101: Instance Port Config
Note: In a network with both GVRP and MSTP enabled, GVRP packets are forwarded along the CIST. If you want to broadcast packets of a specific VLAN through GVRP, please be sure to map the VLAN to the CIST when configuring the MSTP VLAN-instance mapping table. For detailed introduction of GVRP, please refer to GVRP function page.
Page 102: Stp Security
Priority: Enter the priority of the port in the instance. It is an important criterion on determining if the port connected to this port will be chosen as the root port. Path Cost: Path Cost is used to choose the path and calculate the path costs of ports in an MST region.
Page 103 Loop Protect  In a stable network, a switch maintains the states of ports by receiving and processing BPDU packets from the upstream switch. However, when link congestions or link failures occurred to the network, a down stream switch does not receive BPDU packets for certain period, which results in spanning trees being regenerated and roles of ports being reselected, and causes the blocked ports to transit to forwarding state.
Page 104 With BPDU filter function enabled, a port does not receive or forward BPDUs, but it sends out its own BPDUs. Such a mechanism prevents the switch from being attacked by BPDUs so as to guarantee generation the spanning trees correct. Choose the menu Spanning Tree→STP Security→Port Protect to load the following page.
Page 105: Tc Protect
7.4.2 TC Protect When TC Protect is enabled for the port on Port Protect page, the TC threshold and TC protect cycle need to be configured on this page. Choose the menu Spanning Tree→STP Security→TC Protect to load the following page. Figure 7-11 TC Protect The following entries are displayed on this screen: TC Protect...
Page 106 Configuration Procedure  Configure Switch A:  Step Operation Description Configure ports On VLAN→802.1Q VLAN page, configure the link type of the related ports as Trunk, and add the ports to VLAN101-VLAN106. The detailed instructions can be found in the section 802.1Q VLAN.
Page 107 Configure Switch C:  Step Operation Description Configure ports On VLAN→802.1Q VLAN page, configure the link type of the related ports as Trunk, and add the ports to VLAN101-VLAN106. The detailed instructions can be found in the section 802.1Q VLAN. Enable STP function On Spanning Tree→STP Config→STP Config page, enable STP function and select MSTP version.
Page 108 The configuration procedure for switch E and F is the same with that for switch D.  The topology diagram of the two instances after the topology is stable  For Instance 1 (VLAN 101, 103 and 105), the red paths in the following figure are connected ...
Page 109: Chapter 8 Multicast
Chapter 8 Multicast Multicast Overview  In the network, packets are sent in three modes: unicast, broadcast and multicast. In unicast, the source server sends separate copy information to each receiver. When a large number of users require this information, the server must send many pieces of information with the same content to the users.
Page 110 Multicast Address  1. Multicast IP Address: As specified by IANA (Internet Assigned Numbers Authority), Class D IP addresses are used as destination addresses of multicast packets. The multicast IP addresses range from 224.0.0.0~239.255.255.255. The following table displays the range and description of several special multicast IP addresses.
Page 111: Igmp Snooping
IGMP Snooping  In the network, the hosts apply to the near Router for joining (leaving) a multicast group by sending IGMP (Internet Group Management Protocol) messages. When the up-stream device forwards down the multicast data, the switch is responsible for sending them to the hosts. IGMP Snooping is a multicast control mechanism, which can be used on the switch for dynamic registration of the multicast group.
Page 112: Snooping Config
3. IGMP Leave Message The host, running IGMPv1, does not send IGMP leave message when leaving a multicast group, as a result, the switch can not get the leave information of the host momentarily. However, after leaving the multicast group, the host does not send IGMP report message any more, so the switch will remove the port from the corresponding multicast address table when its member port time times out.
Page 113: Port Config
Figure 8-4 Basic Config The following entries are displayed on this screen: Global Config  IGMP Snooping: Select Enable/Disable IGMP Snooping function globally on the switch. Unknown Multicast: Select the operation for the switch to process unknown multicast, Forward or Discard. IGMP Snooping Status ...
Page 114: Vlan Config
Figure 8-5 Port Config The following entries are displayed on this screen: Port Config  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select the desired port for IGMP Snooping feature configuration. It is multi-optional.
Page 115 Figure 8-6 VLAN Config The following entries are displayed on this screen: VLAN Config  VLAN ID: Enter the VLAN ID to enable IGMP Snooping for the desired VLAN. Router Port Time: Specify the aging time of the router port. Within this time, if the switch doesn’t receive IGMP query message from the router port, it will consider this port is not a router port any more.
Page 116: Multicast Vlan
Note: The settings here will be invalid when multicast VLAN is enabled Configuration procedure: Step Operation Description Enable IGMP Snooping Required. Enable IGMP Snooping globally on the switch function port Multicast→IGMP Snooping→Snooping Config and Port Config page. Configure multicast Optional. Configure the multicast parameters for VLANs on parameters for VLANs Multicast→IGMP Snooping→VLAN Config page.
Page 117 Multicast VLAN: Select Enable/Disable Multicast VLAN feature. VLAN ID: Enter the VLAN ID of the multicast VLAN. Router Port Time: Specify the aging time of the router port. Within this time, if the switch doesn’t receive IGMP query message from the router port, it will consider this port is not a router port any more.
Page 118: Application Example For Multicast Vlan
Step Operation Description Look over the configuration If it is successfully configured, the VLAN ID of the multicast VLAN will be displayed in the IGMP Snooping Status table on the Multicast→IGMP Snooping→Snooping Config page. 8.2 Application Example for Multicast VLAN Network Requirements ...
Page 119: Multicast Ip
Step Operation Description Configure ports On VLAN→802.1Q VLAN function pages. For port 3, configure its link type as GENERAL and its egress rule as TAG, and add it to VLAN3, VLAN4 and VLAN5. For port 4, configure its link type as GENERAL and its egress rule as UNTAG, and add it to VLAN3 and VLAN 4.
Page 120: Static Multicast Ip
Multicast IP: Enter the multicast IP address the desired entry must carry. VLAN ID: Enter the VLAN ID the desired entry must carry. Port: Select the port number the desired entry must carry. Type: Select the type the desired entry must carry. ...
Page 121: Multicast Filter
VLAN ID: Enter the VLAN ID of the multicast IP. Forward Port: Enter the forward port of the multicast group. Search Option  Search Option: Select the rules for displaying multicast IP table to find the desired entries quickly.  All: Displays all static multicast IP entries.
Page 122: Port Filter
Figure 8-10 Multicast Filter The following entries are displayed on this screen: Create IP-Range  IP Range ID: Enter the IP-range ID. Start Multicast IP: Enter start multicast IP of the IP-range you set. End Multicast IP: Enter end multicast IP of the IP-range you set. IP-Range Table ...
Page 123 Figure 8-11 Port Filter The following entries are displayed on this screen: Port Filter Config  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select the desired port for multicast filtering. It is multi-optional. Port: Displays the port number.
Page 124: Packet Statistics
Configuration Procedure: Step Operation Description Configure IP-Range Required. Configure IP-Range filtered Multicast→Multicast Filter→IP-Range page. Configure multicast filter Optional. Configure multicast filter rules for ports on rules for ports Multicast→Multicast Filter→Port Filter page. 8.5 Packet Statistics On this page you can view the multicast data traffic on each port of the switch, which facilitates you to monitor the IGMP messages in the network.
Page 125 Port: Displays the port number of the switch. Query Packet: Displays the number of query packets the port received. Report Packet (V1): Displays the number of IGMPv1 report packets the port received. Report Packet (V2): Displays the number of IGMPv2 report packets the port received. Report Packet (V3): Displays the number of IGMPv3 report packets the port received.
Page 126: Chapter 9 Qos
Chapter 9 QoS QoS (Quality of Service) functions to provide different quality of service for various network applications and requirements and optimize the bandwidth resource distribution so as to provide a network service experience of a better quality.  This switch classifies the ingress packets, maps the packets to different priority queues and then forwards the packets according to specified scheduling algorithms to implement QoS function.
Page 127 2. 802.1P Priority Figure 9-2 802.1Q frame As shown in the figure above, each 802.1Q Tag has a Pri field, comprising 3 bits. The 3-bit priority field is 802.1p priority in the range of 0 to 7. 802.1P priority determines the priority of the packets based on the Pri value.
Page 128 Figure 9-4 SP-Mode WRR-Mode: Weight Round Robin Mode. In this mode, packets in all the queues are sent in order based on the weight value for each queue and every queue can be assured of a certain service time. The weight value indicates the occupied proportion of the resource. WRR queue overcomes the disadvantage of SP queue that the packets in the queues with lower priority can not get service for a long time.
Page 129: Diffserv
9.1 DiffServ This switch classifies the ingress packets, maps the packets to different priority queues and then forwards the packets according to specified scheduling algorithms to implement QoS function. This switch implements three priority modes based on port, on 802.1P and on DSCP, and supports four queue scheduling algorithms.
Page 130: Dscp Priority
Configuration Procedure: Step Operation Description Select the port priority Required. On QoS→DiffServ→Port Priority page, configure the port priority. Configure mapping Required. On QoS→DiffServ→802.1P/CoS mapping relation between the CoS page, configure the mapping relation between the CoS priority and TC and TC. Select a schedule mode Required.
Page 131: P/Cos Mapping
Priority Level  DSCP: Indicates the priority determined by the DS region of IP datagram. It ranges from 0 to 63. Priority Level: Indicates the priority level the packets with tag are mapped to. The priority levels are labeled as TC0, TC1, TC2 and TC3. Note: To complete QoS function configuration, you have to go to the Schedule Mode page to select a schedule mode after the configuration is finished on this page.
Page 132: Schedule Mode
The following entries are displayed on this screen: 802.1P Priority Config  802.1P Priority: Select Enable/Disable 802.1P Priority. Priority and CoS-mapping Config  Tag-id/Cos-id: Indicates the precedence level defined by IEEE802.1P and the CoS ID. Queue TC-id: Indicates the priority level of egress queue the packets with tag and CoS-id are mapped to.
Page 133: Bandwidth Control
WRR-Mode: Weight Round Robin Mode. In this mode, packets in all the queues are sent in order based on the weight value for each queue. The weight value ratio of TC0, TC1, TC2 and TC3 is 1:2:4:8. SP+WRR-Mode: Strict-Priority + Weight Round Robin Mode. In this mode, this switch provides two scheduling groups, SP group and WRR group.
Page 134: Storm Control
The following entries are displayed on this screen:  Rate Limit Config Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select the desired port for Rate configuration. It is multi-optional. Port: Displays the port number of the switch.
Page 135 Figure 9-11 Storm Control The following entries are displayed on this screen:  Storm Control Config Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select the desired port for Storm Control configuration. It is multi-optional.
Page 136: Voice Vlan
9.3 Voice VLAN Voice VLANs are configured specially for voice data stream. By configuring Voice VLANs and adding the ports with voice devices attached to voice VLANs, you can perform QoS-related configuration for voice data, ensuring the transmission priority of voice data stream and voice quality.
Page 137 Port Voice Voice Link type of the port and processing mode VLAN Mode Stream Type ACCESS: Not supported. TRUNK: Supported. The default VLAN of the port can not be TAG voice voice VLAN. stream GENERAL: Supported. The default VLAN of the port can not be voice VLAN and the egress rule of the access port in the voice VLAN should be TAG.
Page 138: Global Config
Note: Don’t transmit voice stream together with other business packets in the voice VLAN except for some special requirements. The Voice VLAN function can be implemented on Global Config, Port Config and OUI Config pages. 9.3.1 Global Config On this page, you can configure the global parameters of the voice VLAN, including VLAN ID, aging time, the transmission priority of the voice packets and so on.
Page 139 Figure 9-13 Port Config Note: To enable voice VLAN function for the LAG member port, please ensure its member state accords with its port mode. If a port is a member port of voice VLAN, changing its port mode to be “Auto” will make the port leave the voice VLAN and will not join the voice VLAN automatically until it receives voice streams.
Page 140: Oui Config
LAG: Displays the LAG number which the port belongs to. 9.3.3 OUI Config The switch supports OUI create and add the MAC address of the special voice device to the OUI table of the switch. The switch determines whether a received packet is a voice packet by checking its OUI address.
Page 141 Step Operation Description Create VLAN Required. On VLAN→802.1Q VLAN→Port Config page, click the Create button to create a VLAN. Add OUI address Optional. On QoS→Voice VLAN→OUI Config page, you can check whether the switch is supporting the OUI template or not. If not, please add the OUI address. Configure the parameters Required.
Page 142: Chapter 10 Acl
Chapter 10 ACL ACL (Access Control List) is used to filter packets by configuring match rules and process policies of packets in order to control the access of the illegal users to the network. Besides, ACL functions to control traffic flows and save network resources. It provides a flexible and secured access control policy and facilitates you to control the network security.
Page 143: Time-Range Create
10.1.2 Time-Range Create On this page you can create time-ranges. Choose the menu ACL→Time-Range→Time-Range Create to load the following page. Figure 10-2 Time-Range Create Note: To successfully configure time-ranges, please firstly specify time-slices and then time-ranges. The following entries are displayed on this screen: Create Time-Range ...
Page 144: Holiday Config
10.1.3 Holiday Config Holiday mode is applied as a different secured access control policy from the week mode. On this page you can define holidays according to your work arrangement. Choose the menu ACL→Time-Range→Holiday Config to load the following page. Figure 10-3 Holiday Configuration The following entries are displayed on this screen: Create Holiday...
Page 145: Acl Create
Choose the menu ACL→ACL Config→ACL Summary to load the following page. Figure 10-4 ACL Summary The following entries are displayed on this screen: Search Option  Select ACL: Select the ACL you have created ACL Type: Displays the type of the ACL you select. Rule Order: Displays the rule order of the ACL you select.
Page 146: Standard-Ip Acl
Choose the menu ACL→ACL Config→MAC ACL to load the following page. Figure10-6 Create MAC Rule The following entries are displayed on this screen: Create MAC-Rule  ACL ID: Select the desired MAC ACL for configuration. Rule ID: Enter the rule ID. Operation: Select the operation for the switch to process packets which match the rules.
Page 147: Extend-Ip Acl
Figure10-7 Create Standard-IP Rule The following entries are displayed on this screen: Create Standard-IP Rule  ACL ID: Select the desired Standard-IP ACL for configuration. Rule ID: Enter the rule ID. Operation: Select the operation for the switch to process packets which match the rules.
Page 148 Figure10-8 Create Extend-IP Rule The following entries are displayed on this screen: Create Extend-IP Rule  ACL ID: Select the desired Extend-IP ACL for configuration. Rule ID: Enter the rule ID. Operation: Select the operation for the switch to process packets which match the rules.
Page 149: Policy Config
S-Port: Configure TCP/IP source port contained in the rule when TCP/UDP is selected from the pull-down list of IP Protocol. D-Port: Configure TCP/IP destination port contained in the rule when TCP/UDP is selected from the pull-down list of IP Protocol. DSCP: Enter the DSCP information contained in the rule.
Page 150: Policy Create
QoS Remark: Displays the QoS remark added to the policy. Operation: Click the Edit button to modify the action. 10.3.2 Policy Create On this page you can create the policy. Choose the menu ACL→Policy Config→Policy Create to load the following page. Figure 10-10 Create Policy The following entries are displayed on this screen: Create Policy...
Page 151: Policy Binding
Select Policy: Select the name of the policy. Select ACL: Select the ACL for configuration in the policy. S-Mirror: Select S-Mirror to mirror the data packets in the policy to the specific port. S-Condition: Select S-Condition to limit the transmission rate of the data packets in the policy.
Page 152: Port Binding
The following entries are displayed on this screen: Search Options  Show Mode: Select a show mode appropriate to your needs. Policy Bind Table  Select: Select the desired entry to delete the corresponding binding policy. Index: Displays the index of the binding policy. Policy Name: Displays the name of the binding policy.
Page 153: Application Example For Acl
Figure10-14 Bind the policy to the VLAN The following entries are displayed on this screen: VLAN-Bind Config  Policy Name: Select the name of the policy you want to bind. VLAN ID: Enter the ID of the VLAN you want to bind. VLAN-Bind Table ...
Page 154 RD, configure port 16 and port 2 as the members of VLAN 6. Connect RD department to port 16 of TL-SL5428E, and configure the link type of port 16 as GENERAL and its PVID as 6. The IP range of VLAN 6 is 172.31.70.0.
Page 155 Step Operation Description Configure On ACL→ACL Config→ACL Create page, create ACL 100. requirement On ACL→ACL Config→Standard-IP ACL page, select ACL 100, and 3 create Rule 1, configure operation as Deny, configure S-IP as 172.31.70.1 and mask as 255.255.255.0, configure D-IP as 172.31.50.1 and mask as 255.255.255.0, configure the time-range as No Limit.
Page 156: Chapter 11 Network Security
Chapter 11 Network Security Network Security module is to provide the multiple protection measures for the network security, including five submenus: IP-MAC Binding, ARP Inspection, IP Source Guard, DoS Defend and 802.1X. Please configure the functions appropriate to your need. 11.1 IP-MAC Binding The IP-MAC Binding function allows you to bind the IP address, MAC address, VLAN ID and the connected Port number of the Host together.
Page 157: Manual Binding
The following entries are displayed on this screen: Search Option  Source: Select a Source from the pull-down list and click the Search button to view your desired entry in the Binding Table.  All: All the bound entries will be displayed. ...
Page 158: Arp Scanning
Figure 11-2 Manual Binding The following entries are displayed on this screen: Manual Binding Option  Host Name: Enter the Host Name. IP Address: Enter the IP Address of the Host. MAC Address: Enter the MAC Address of the Host. VLAN ID: Enter the VLAN ID.
Page 159 address of the Host on Network layer. MAC address, the address of the Host on Data link layer, is necessary for the packet to reach the very device. So the destination IP address carried in a packet need to be translated into the corresponding MAC address. ARP functions to translate the IP address into the corresponding MAC address and maintain an ARP Table, where the latest used IP address-to-MAC address mapping entries are stored.
Page 160: Dhcp Snooping
Figure 11-4 ARP Scanning The following entries are displayed on this screen: Scanning Option  Start IP Address: Specify the Start IP Address. End IP Address: Specify the End IP Address. VLAN ID: Enter the VLAN ID. If blank, the switch will send the untagged packets for scanning.
Page 161 DHCP Working Principle  DHCP works via the “Client/Server” communication mode. The Client applies to the Server for configuration. The Server assigns the configuration information, such as the IP address, to the Client, so as to reach a dynamic employ of the network source. A Server can assign the IP address for several Clients, which is illustrated in the following figure.
Page 162 （2） DHCP-OFFER Stage: Upon receiving the DHCP-DISCOVER packet, the DHCP Server selects an IP address from the IP pool according to the assigning priority of the IP addresses and replies to the Client with DHCP-OFFER packet carrying the IP address and other information.
Page 163 Figure 11-7 DHCP Cheating Attack Implementation Procedure DHCP Snooping feature only allows the port connected to the DHCP Server as the trusted port to forward DHCP packets and thereby ensures that users get proper IP addresses. DHCP Snooping is to monitor the process of the Host obtaining the IP address from DHCP server, and record the IP address, MAC address, VLAN and the connected Port number of the Host for automatic binding.
Page 164 Figure 11-8 DHCP Snooping Note: If you want to enable the DHCP Snooping feature for the member port of LAG, please ensure the parameters of all the member ports are the same. The following entries are displayed on this screen: DHCP Snooping Config ...
Page 165: Arp Inspection
Decline Flow Control: Select the value to specify the Decline Flow Control. The traffic flow of the corresponding port will be limited to be this value if the transmission rate of the Decline packets exceeds the Decline Threshold. Option 82 Config ...
Page 166 ARP, such as imitating Gateway, cheating Gateway, cheating terminal Hosts and ARP Flooding Attack, frequently occur to the network, especially to the large network such as campus network and so on. The following part will simply introduce these ARP attacks. Imitating Gateway ...
Page 167 Figure 11-10 ARP Attack – Cheating Gateway As the above figure shown, the attacker sends the fake ARP packets of Host A to the Gateway, and then the Gateway will automatically update its ARP table after receiving the ARP packets. When the Gateway tries to communicate with Host A in LAN, it will encapsulate this false destination MAC address for packets, which results in a breakdown of the normal communication.
Page 168 As the above figure shown, the attacker sends the fake ARP packets of Host A to Host B, and then Host B will automatically update its ARP table after receiving the ARP packets. When Host B tries to communicate with Host A, it will encapsulate this false destination MAC address for packets, which results in a breakdown of the normal communication.
Page 169: Arp Detect
ARP Flooding Attack  The attacker broadcasts a mass of various fake ARP packets in a network segment to occupy the network bandwidth viciously, which results in a dramatic slowdown of network speed. Meantime, the Gateway learns the false IP address-to-MAC address mapping entries from these ARP packets and updates its ARP table.
Page 170: Arp Defend
Trusted Port  Trusted Port: Select the port for which the ARP Detect function is unnecessary as the Trusted Port. The specific ports, such as up-linked port, routing port and LAG port, should be set as Trusted Port. To ensure the normal communication of the switch, please configure the ARP Trusted Port before enabling the ARP Detect function.
Page 171: Arp Statistics
Figure 11-14 ARP Defend The following entries are displayed on this screen: ARP Defend  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select your desired port for configuration. It is multi-optional. Port: Displays the port number.
Page 172: Ip Source Guard
Figure 11-15 ARP Statistics The following entries are displayed on this screen: Auto Refresh  Auto Refresh: Enable/Disable the Auto Refresh feature. Refresh Interval: Specify the refresh interval to display the ARP Statistics. Illegal ARP Packet  Port: Displays the port number. Trusted Port: Indicates the port is an ARP Trusted Port or not.
Page 173: Dos Defend
Figure 11-16 IP Source Guard The following entries are displayed on this screen: IP Source Guard Config  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select your desired port for configuration. It is multi-optional. Port: Displays the port number.
Page 174 packets may incur a breakdown of the network. The switch can defend several types of DoS attack listed in the following table. DoS Attack Type Description Land Attack The attacker sends a specific fake SYN packet to the destination Host. Since both the source IP address and the destination IP address of the SYN packet are set to be the IP address of the Host, the Host will be trapped in an endless circle for building the initial connection.
Page 175: Dos Defend
11.4.1 DoS Defend On this page, you can enable the DoS Defend type appropriate to your need. Choose the menu Network Security→DoS Defend→DoS Defend to load the following page. Figure 11-17 DoS Defend The following entries are displayed on this screen: Defend Config ...
Page 176 Figure 11-18 DoS Detect The following entries are displayed on this screen: Detect Config  Detect Time: Specify the detect time for each DoS attack type except the flooding attack type. Detect: Click the Detect button to start the detection. The switch will detect each type of the DoS attack in turn.
Page 177 Figure 11-19 Architecture of 802.1X authentication （1） Supplicant System: The supplicant system is an entity in LAN and is authenticated by the authenticator system. The supplicant system is usually a common user terminal computer. An 802.1X authentication is initiated when a user launches client program on the supplicant system.
Page 178 can also launch an 802.1X client program to initiate an 802.1X authentication through the sending of an EAPOL-Start packet to the switch, This TP-LINK switch can authenticate supplicant systems in EAP relay mode or EAP terminating mode. The following illustration of these two modes will take the 802.1X authentication procedure initiated by the supplicant system for example.
Page 179 The RADIUS server compares the received encrypted password (contained in a RADIUS Access-Request packet) with the locally-encrypted password. If the two match, it will then send feedbacks (through a RADIUS Access-Accept packet and an EAP-Success packet) to the switch to indicate that the supplicant system is authorized. The switch changes the state of the corresponding port to accepted state to allow the supplicant system access the network.
Page 180: Global Config
the authentication request packet if the RADIUS server fails to respond in the specified timeout period. （3） Quiet-period timer (Quiet Period): This timer sets the quiet-period. When a supplicant system fails to pass the authentication, the switch quiets for the specified period before it processes another authentication request re-initiated by the supplicant system.
Page 181: Port Config
The following entries are displayed on this screen: Global Config  802.1X: Enable/Disable the 802.1X function. Auth Method: Select the Authentication Method from the pull-down list.  EAP-MD5: IEEE 802.1X authentication system uses extensible authentication protocol (EAP) to exchange information between the switch and the client.
Page 182 Figure 11-23 Port Config The following entries are displayed on this screen: Port Config  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Select: Select your desired port for configuration. It is multi-optional. Port: Displays the port number.
Page 183: Radius Server
11.5.3 Radius Server RADIUS (Remote Authentication Dial-In User Service) server provides the authentication service for the switch via the stored client information, such as the user name, password, etc, with the purpose to control the authentication and accounting status of the clients. On this page, you can configure the parameters of the authentication server.
Page 184 Note: 1. The 802.1X function takes effect only when it is enabled globally on the switch and for the port. 2. The 802.1X function can not be enabled for LAG member ports. That is, the port with 802.1X function enabled can not be added to the LAG. 3.
Page 185: Chapter 12 Snmp
Chapter 12 SNMP SNMP Overview  SNMP (Simple Network Management Protocol) has gained the most extensive application on the UDP/IP networks. SNMP provides a management frame to monitor and maintain the network devices. It is used for automatically managing the various network devices no matter the physical differences of the devices.
Page 186 failing to pass community name authentication are discarded. The community name can limit access to SNMP Agent from SNMP NMS, functioning as a password. SNMP v2c: SNMP v2c also adopts community name authentication. It is compatible with SNMP v1 while enlarges the function of SNMP v1. SNMP v3: Basing on SNMP v1 and SNMP v2c, SNMP v3 extremely enhances the security and manageability.
Page 187: Snmp Config
SNMP module is used to configure the SNMP function of the switch, including three submenus: SNMP Config, Notification and RMON. 12.1 SNMP Config The SNMP Config can be implemented on the Global Config, SNMP View, SNMP Group, SNMP User and SNMP Community pages. 12.1.1 Global Config To enable SNMP function, please configure the SNMP function globally on this page.
Page 188: Snmp View
12.1.2 SNMP View The OID (Object Identifier) of the SNMP packets is used to describe the managed objects of the switch, and the MIB (Management Information Base) is the set of the OIDs. The SNMP View is created for the SNMP management station to manage MIB objects. Choose the menu SNMP→SNMP Config→SNMP View to load the following page.
Page 189 Figure 12-5 SNMP Group The following entries are displayed on this screen: Group Config  Group Name: Enter the SNMP Group name. The Group Name, Security Model and Security Level compose the identifier of the SNMP Group. These three items of the Users in one group should be the same. Security Model: Select the Security Model for the SNMP Group.
Page 190: Snmp User
Group Table  Select: Select the desired entry to delete the corresponding group. It's multi-optional. Group Name: Displays the Group Name here. Security Model: Displays the Security Model of the group. Security Level: Displays the Security Level of the group. Read View: Displays the Read View name in the entry.
Page 191 User Type: Select the type for the User.  Local User: Indicates that the user is connected to a local SNMP engine.  Remote User: Indicates that the user is connected to a remote SNMP engine. Group Name: Select the Group Name of the User. The User is classified to the corresponding Group according to its Group Name, Security Model and Security Level.
Page 192: Snmp Community
12.1.5 SNMP Community SNMP v1 and SNMP v2c adopt community name authentication. The community name can limit access to the SNMP agent from SNMP network management station, functioning as a password. If SNMP v1 or SNMP v2c is employed, you can directly configure the SNMP Community on this page without configuring SNMP Group and User.
Page 193 Configuration Procedure: If SNMPv3 is employed, please take the following steps:  Step Operation Description Enable SNMP function globally. Required. On the SNMP→SNMP Config→Global Config page, enable SNMP function globally. Create SNMP View. Required. On the SNMP→SNMP Config→SNMP View page, create SNMP View of the management agent.
Page 194: Notification
12.2 Notification With the Notification function enabled, the switch can initiatively report to the management station about the important events that occur on the Views (e.g., the managed device is rebooted), which allows the management station to monitor and process the events in time. The notification information includes the following two types: Trap ：...
Page 195: Rmon
Type: Select the type for the notifications.  Trap: Indicates traps are sent.  Inform: Indicates informs are sent. The Inform type has a higher security than the Trap type. Retry: Specify the amount of times the switch resends an inform request.
Page 196: History Control
RMON Group Function History Group After a history group is configured, the switch collects and records network statistics information periodically, based on which the management station can monitor network effectively. Event Group Event Group is used to define RMON events. Alarms occur when an event is detected.
Page 197: Event Config
12.3.2 Event Config On this page, you can configure the RMON events. Choose the menu SNMP→RMON→Event Config to load the following page. Figure 12-10 Event Config The following entries are displayed on this screen: Event Table  Select: Select the desired entry for configuration. Index: Displays the index number of the entry.
Page 198 Figure 12-11 Alarm Config The following entries are displayed on this screen: Alarm Table  Select: Select the desired entry for configuration. Index: Displays the index number of the entry. Variable: Select the alarm variables from the pull-down list. Port: Select the port on which the Alarm entry acts.
Page 199 Owner: Enter the name of the device or user that defined the entry. Status: Select Enable/Disable the corresponding alarm entry. Note: When alarm variables exceed the Threshold on the same direction continuously for several times, an alarm event will only be generated on the first time, that is, the Rising Alarm and Falling Alarm are triggered alternately for that the alarm following to Rising Alarm is certainly a Falling Alarm and vice versa.
Page 200: Chapter 13 Lldp
Chapter 13 LLDP LLDP (Link Layer Discovery Protocol) is a Layer 2 protocol that is used for network devices to advertise their own device information periodically to neighbors on the same IEEE 802 local area network. The advertised information, including details such as device identification, capabilities and configuration settings, is represented in TLV (Type/Length/Value) format according to the IEEE 802.1ab standard, and these TLVs are encapsulated in LLDPDU (Link Layer Discovery Protocol Data Unit).
Page 201  Disable: the port cannot transmit or receive LLDPDUs. LLDPDU transmission mechanism  If the ports are working in TxRx or Tx mode, they will advertise local information by sending LLDPDUs periodically.  If there is a change in the local device, the change notification will be advertised. To prevent a series of successive LLDPDUs transmissions during a short period due to frequent changes in local device, a transmission delay timer is set by network management to ensure that there is a defined minimum time between successive LLDP...
Page 202 TLV Type TLV Name Description Usage in LLDPDU Time To Live Indicates the number of seconds that the Mandatory neighbor device is to regard the local information to be valid. Port Description Identifies the description string of the port. Optional System Name Identifies the system name.
Page 203: Basic Config
System Name TLV The System Name TLV allows network management to advertise the system's assigned name, which should be the system's fully qualified domain name. Management Address The Management Address TLV identifies an address associated with the local LLDP agent that may be used to reach higher entities to assist discovery by network management.
Page 204: Port Config
Figure 13-1 Global Configuration The following entries are displayed on this screen: Global Config  LLDP: Enable/disable LLDP function globally. Parameters Config  Transmit Interval: Enter the interval for the local device to transmit LLDPDU to its neighbors. The default value is 30. Hold Multiplier: Enter a multiplier on the Transmit Interval.
Page 205: Device Info
Figure 13-2 Port Configuration The following entries are displayed on this screen: LLDP Port Config  Port Select: Select the desired port to configure. Admin Status: Select the port’s LLDP operating mode: Tx&Rx: Send and receive LLDP frames.  Rx_Only: Only receive LLDP frames. ...
Page 206: Neighbor Info
Figure 13-3 Local Information The following entries are displayed on this screen: Auto Refresh  Auto Refresh: Enable/Disable the auto refresh function. Refresh Rate: Specify the auto refresh rate. Local Info  Enter the desired port number and click Select to display the information of the corresponding port.
Page 207: Device Statistics
The following entries are displayed on this screen: Auto Refresh  Auto Refresh: Enable/Disable the auto refresh function. Refresh Rate: Specify the auto refresh rate. Neighbor Info  Port Select: Click the Select button to quick-select the corresponding port based on the port number you entered. Local Port: Displays the local port number connecting to the neighbor device.
Page 208 Figure 13-5 Device Statistics The following entries are displayed on this screen: Auto Refresh  Auto Refresh: Enable/Disable the auto refresh function. Refresh Rate: Specify the auto refresh rate. Global Statistics  Last Update: Displays latest update time of the statistics. Total Inserts: Displays the number of neighbors inserted till last update time.
Page 209 Receive Total: Displays the number of LLDPDUs received by this port. Discards: Displays the number of LLDPDUs discarded by this port. Errors: Displays the number of error LLDPDUs received by this port. Ageouts: Displays the number of overtime neighbors linking to this port. TLV Discards: Displays the number of TLVs dropped by this port.
Page 210: Chapter 14 Cluster
Chapter 14 Cluster With the development of network technology, the network scale is getting larger and more network devices are required, which may result in a more complicated network management system. As a large number of devices need to be assigned different network addresses and every management device needs to be respectively configured to meet the application requirements, manpower are needed.
Page 211: Ndp
The commander switch discovers and determines candidate switches by collecting related  information. After being added to the cluster, the candidate switch becomes to be the member switch,  After being removed from the cluster, the member switch becomes to be the candidate switch. ...
Page 212: Ndp Summary
Neighbor  Search Option: Select the information the desired entry should contain and then click the Search button to display the desired entry in the following Neighbor Information table. Neighbor Info  Native Port: Displays the port number of the switch. Remote Port: Displays the port number of the neighbor switch which is connected to the corresponding port.
Page 213: Ndp Config
NDP: Displays the global NDP status (enabled or disabled) for the switch. Aging Time: Displays the period for the neighbor switch to keep the NDP packets from this switch. Hello Time: Displays the interval to send NDP packets. Port Status ...
Page 214: Ntdp
The following entries are displayed on this screen: Global Config  NDP: Select Enable/Disable NDP function globally. Aging Time: Enter the period for the neighbor switch to keep the NDP packets from this switch. Hello Time: Enter the interval to send NDP packets. Port Config ...
Page 215 Figure 14-5 Device Table The following entries are displayed on this screen: Device Table  Device Type: Displays the device description collected through NTDP. Device MAC: Displays the MAC address of this device. Cluster Name: Displays the cluster name of this device. Role: Displays the role this device plays in the cluster.
Page 216: Ntdp Summary
14.2.2 NTDP Summary On this page you can view the NTDP configuration. Choose the menu Cluster→NTDP→NTDP Summary to load the following page. Figure 14-7 NTDP Summary The following entries are displayed on this screen: Global Config  NTDP: Displays the NTDP status (enabled or disabled) of the switch globally.
Page 217: Ntdp Config
14.2.3 NTDP Config On this page you can configure NTDP globally. Choose the menu Cluster→NTDP→NTDP Config to load the following page. Figure 14-8 NTDP Config The following entries are displayed on this screen: Global Config  NTDP: Select Enable/Disable NTDP for the switch globally. NTDP Interval Time: Enter the interval to collect topology information.
Page 218: Cluster
Port Config  Select: Select the desired port for NTDP status configuration. Port: Displays the port number of the switch. NTDP: Displays NTDP status (enabled or disabled) of the current port. Enable: Click the Enable button to enable NTDP feature for the port you select.
Page 219 For a commander switch，the following page is displayed:  Figure 14-10 Cluster Summary for Commander Switch The following entries are displayed on this screen: Global Config  Cluster: Displays the cluster status (enabled or disabled) of the switch. Cluster Role: Displays the role the switch plays in the cluster.
Page 220: Cluster Config
Hops: Displays the hop count from the member switch to the commander switch. For a member switch, the following page is displayed:  Figure 14-11 Cluster Summary for Member Switch The following entries are displayed on this screen: Global Config ...
Page 221 For a candidate switch, the following page is displayed.  Figure 14-13 Cluster Configuration for Candidate Switch The following entries are displayed on this screen: Current Role  Role: Displays the role the current switch plays in the cluster. Role Change ...
Page 222 The following entries are displayed on this screen: Current Role  Role: Displays the role the current switch plays in the cluster. Role Change  Candidate: Select this option to change the role of the switch to be candidate switch. Cluster Config ...
Page 223: Member Config
The following entries are displayed on this screen: Current Role  Role: Displays the role the current switch plays in the cluster. Role Change  Candidate: Select this option to change the role of the switch to be candidate switch. 14.3.3 Member Config When this switch is the commander switch of the cluster, via the commander switch you can manually add a candidate switch to the cluster as well as remove the designated member switch...
Page 224: Cluster Topology
Manage: Click the Manage button after selecting the desired entry to log on to the Web management page of the corresponding member switch. 14.3.4 Cluster Topology On this page you can see the whole cluster topology. Click the node switch to directly log on to the corresponding Web management page for you to configure and manage this switch.
Page 225 If the switch is a commander switch in the cluster, please take the following steps.  Step Operation Description Enable the NDP function Optional. On Cluster→NDP→NDP Config page, enable the globally and for the port, NDP function on the switch. and then configure NDP parameters Enable the NTDP function...
Page 226: Application Example For Cluster Function
14.4 Application Example for Cluster Function Network Requirements  Three switches form cluster, one commander switch and two member switches. The administrator manages all the switches in the cluster via the commander switch. Port 1 of the commander switch is connecting to the external network, port 2 is connecting to ...
Page 227 Step Operation Description Create a cluster and configure On Cluster→Cluster→Cluster Config page, configure the related parameters the role as Commander and enter the related information. IP pool: 175.128.0.1 Mask: 255.255.255.0 Configure the member switch On Cluster→Cluster→Member Config page, select the member switch and click the Manage button to log on to its Web management page.
Page 228: Chapter 15 Maintenance
Chapter 15 Maintenance Maintenance module, assembling the commonly used system tools to manage the switch, provides the convenient method to locate and solve the network problem. （1） System Monitor: Monitor the utilization status of the memory and the CPU of switch. （2）...
Page 229: Memory Monitor
15.1.2 Memory Monitor Choose the menu Maintenance→System Monitor→Memory Monitor to load the following page. Figure 15-2 Memory Monitor Click the Monitor button to enable the switch to monitor and display its Memory utilization rate every four seconds. 15.2 Log The Log system of switch can record, classify and manage the system information effectively, providing powerful support for network administrator to monitor network operation and diagnose malfunction.
Page 230: Log Table
The Log function is implemented on the Log Table, Local Log, Remote Log and Backup Log pages. 15.2.1 Log Table The switch supports logs output to two directions, namely, log buffer and log file. The information in log buffer will be lost after the switch is rebooted or powered off whereas the information in log file will be kept effective even the switch is rebooted or powered off.
Page 231: Remote Log
Figure 15-4 Local Log The following entries are displayed on this screen: Local Log Config  Select: Select the desired entry to configure the corresponding local log. Log Buffer: Indicates the RAM for saving system log. The inforamtion in the log buffer is displayed on the Log Table page.
Page 232: Backup Log
The following entries are displayed on this screen: Log Host  Index: Displays the index of the log host. The switch supports 4 log hosts. Host IP: Configure the IP for the log host. UDP Port: Displays the UDP port used for receiving/sending log information.
Page 233: Loopback
Choose the menu Maintenance→Device Diagnostics→Cable Test to load the following page. Figure 15-7 Cable Test The following entries are displayed on this screen: Cable Test  Port: Select the port for cable testing. Pair: Displays the Pair number. Status: Displays the connection status of the cable connected to the port. The test results of the cable include normal, close, open or impedance.
Page 234: Network Diagnostics
Figure 15-8 Loopback The following entries are displayed on this screen: Loopback Type  Internal: Select Internal to test whether the port is available. External: Select External to test whether the device connected to the port of the switch is available Loopback Port ...
Page 235: Tracert
Figure 15-9 Ping The following entries are displayed on this screen: Ping Config  Destination IP: Enter the IP address of the destination node for Ping test. Ping Times: Enter the amount of times to send test data during Ping testing. The default value is recommended.
Page 236 Figure 15-10 Tracert The following entries are displayed on this screen: Tracert Config  Destination IP: Enter the IP address of the destination device. Max Hop: Specify the maximum number of the route hops the test data can pass through. Tracert Result ...
Page 237: Chapter 16 System Maintenance Via Ftp
Chapter 16 System Maintenance via FTP The firmware can be downloaded to the switch via FTP function. FTP (File Transfer Protocol), a protocol in the application layer, is mainly used to transfer files between the remote server and the local PCs. It is a common protocol used in the IP network for files transfer. If there is something wrong with the firmware of the switch and the switch can not be launched, the firmware can be downloaded to the switch again via FTP function.
Page 238 2） The Connection Description Window will prompt shown as Figure 16-3. Enter a name into the Name field and click OK. Figure 16-3 Connection Description 3） Select the port to connect in Figure 16-4 and click OK. Figure 16-4 Select the port to connect 4）...
Page 239 Figure 16-5 Port Settings 3. Download Firmware via bootrom menu To download firmware to the switch via FTP function, you need to enter into the bootrom menu of the switch and take the following steps. 1） Connect the console port of the PC to the console port of the switch and open hyper terminal.
Page 240 [TP-LINK]: ifconfig ip 172.31.70.22 mask 255.255.255.0 gateway 172.31.70.1 4） Configure the parameters of the FTP server which keeps the upgrade firmware. Later you can download the firmware to the switch from the FTP server. The format of the command is: ftp host xxx.xxx.xxx.xxx user xxxxx pwd xxxxx file xxxxxx.bin. Here take the following parameters of the FTP server as an example.
Page 241: Appendix A: Specifications
Appendix A: Specifications IEEE802.3 10Base-T Ethernet IEEE802.3u 100Base-TX/100Base-FX Fast Ethernet IEEE802.3ab 1000Base-T Gigabit Ethernet IEEE802.3z 1000Base-X Gigabit Ethernet Standards IEEE802.3x Flow Control IEEE802.1p QoS IEEE802.1q VLAN IEEE802.1X Port-based Access Authentication Ethernet: 10Mbps HD，20Mbps FD Transmission Rate Fast Ethernet: 100Mbps HD，200Mbps FD Gigabit Ethernet: 2000Mbps FD 10Base-T: UTP/STP of Cat.
Page 242: Appendix B: Configuring The Pcs
Appendix B: Configuring the PCs In this section, we’ll introduce how to install and configure the TCP/IP correctly in Windows 2000. First make sure your Ethernet Adapter is working, refer to the adapter’s manual if necessary. Configure TCP/IP component On the Windows taskbar, click the Start button, and then click Control Panel. Click the Network and Internet Connections icon, and then click on the Network Connections tab in the appearing window.
Page 243 The following TCP/IP Properties window will display and the IP Address tab is open on this window by default. Figure B-3 Select Use the following IP address. And the following items will be available. If the switch's IP address is 192.168.0.1, specify IP address as 192.168.0.x (x is from 2 to 254), and the Subnet mask as 255.255.255.0.
Page 244: Appendix C: 802.1X Client Software
In 802.1X mechanism, the supplicant Client should be equipped with the corresponding client software complied with 802.1X protocol standard for 802.1X authentication. When the switch TL-SL5428E works as the authenticator system, please take the following instructions to install the TpSupplicant provided on the attached CD for the supplicant Client.
Page 245 Figure C-3 Welcome to the InstallShield Wizard To continue, choose the destination location for the installation files and click Next on the following screen. Figure C-4 Choose Destination Location By default, the installation files are saved on the Program Files folder of system disk. Click the Change button to modify the destination location proper to your need.
Page 246 Figure C-5 Install the Program The InstallShield Wizard is installing TpSupplicant-V2.0 shown as the following screen. Please wait. Figure C-6 Setup Status On the following screen, click Finish to complete the installation. Figure C-7 InstallShield Wizard Complete...
Page 247 Note: Please pay attention to the tips on the above screen. If you have not installed WinPcap 4.0.2 or the higher version on your computer, the 802.1X Client Software TpSupplicant can not work. It’s recommended to go to http://www.winpcap.org to download the latest version of WinPcap for installation.
Page 248 Figure C-10 Uninstall the Application Click Finish to complete. Figure C-11 Uninstall Complete Configuration After completing installation, double click the icon to run the TP-LINK 802.1X Client Software. The following screen will appear. Figure C-12 TP-LINK 802.1X Client Enter the Name and the Password specified in the Authentication Server. The length of Name and Password should be less than 15 characters.
Page 249 Click the Properties button on Figure C-12 to load the following screen for configuring the connection properties. Figure C-13 Connection Properties Send 802.1X protocol packets by Unicast: When this option is selected, the Client will send the EAPOL Start packets to the switch via multicast and send the 802.1X authentication packets via unicast.
Page 250 Figure C-15 Successfully Authenticated Double click the icon on the right corner of desktop, and then the following connection status screen will pop up. Figure C-16 Connection Status...
Page 251 FAQ: Q1: Why does this error dialog box pop up when starting up the TP-LINK 802.1X Client Software? A1: It’s because the supported DLL file is missing. You are suggested to go to http://www.winpcap.org to download WinPcap 4.0.2 or the higher version for installation, and run the client software again.
Page 252: Appendix D: Glossary
Appendix D: Glossary Access Control List (ACL) ACLs can limit network traffic and restrict access to certain users or devices by checking each packet for certain IP or MAC (i.e., Layer 2) information. Boot Protocol (BOOTP) BOOTP is used to provide bootup information for network devices, including IP address information, the address of the TFTP server that contains the devices system files, and the name of the boot file.
Page 253 GMRP allows network devices to register end stations with multicast groups. GMRP requires that any participating network devices or end stations comply with the IEEE 802.1p standard. Group Attribute Registration Protocol (GARP) See Generic Attribute Registration Protocol. IEEE 802.1D Specifies a general method for the operation of MAC bridges, including the Spanning Tree Protocol.
Page 254 Layer 2 Data Link layer in the ISO 7-Layer Data Communications Protocol. This is related directly to the hardware interface for network devices and passes on traffic based on MAC addresses. Link Aggregation See Port Trunk. Link Aggregation Control Protocol (LACP) Allows ports to automatically negotiate a trunked link with LACP-configured ports on another device.
Page 255 Secure Shell (SSH) A secure replacement for remote access functions, including Telnet. SSH can authenticate users with a cryptographic key, and encrypt data connections between management clients and the switch. Simple Network Management Protocol (SNMP) The application protocol in the Internet suite of protocols which offers network management services.

TP-Link TL-SL5428E User Manual

Chapter 1 About this Guide

Chapter 2 Introduction

Chapter 3 Login to the Switch

Chapter 4 System

Chapter 5 Switching

Chapter 6 VLAN

Chapter 7 Spanning Tree

Chapter 8 Multicast

Chapter 9 Qos

Chapter 10 ACL

Chapter 11 Network Security

Chapter 12 SNMP

Chapter 13 LLDP

Chapter 14 Cluster

Chapter 15 Maintenance

Chapter 16 System Maintenance Via FTP

Appendix A: Specifications

Appendix B: Configuring the Pcs

Appendix C: 802.1X Client Software

Appendix D: Glossary

Quick Links

Need help?

Questions and answers

Related Manuals for TP-Link TL-SL5428E

Summary of Contents for TP-Link TL-SL5428E
