Page 1: Installation Guide
Installation Guide TL-SL5428 24-Port 10/100 + 4-Port Gigabit Managed Switch Rev: 1.0.1... - Page 2 Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.
-
Page 3: Table Of Contents
ONTENTS About the TL-SL5428 ......1-1 Overview ..........1-1 Switch Architecture . - Page 4 ABLE OF ONTENTS Connecting to a Power Source ....... . 3-8 Connecting to the Console Port .
- Page 5 ABLE OF ONTENTS Standards ..........C-3 Compliances .
- Page 6 ABLE OF ONTENTS...
- Page 7 ABLES Table 1-1 Port Status LEDs ....... . . 1-4 Table 1-2 System Status LEDs .
- Page 9 IGURES Figure 1-1 Front and Rear Panels ......1-1 Figure 1-2 Port LEDs ........1-3 Figure 1-3 System LEDs .
- Page 10 IGURES viii...
-
Page 11: Figure 1-1 Front And Rear Panels
HAPTER TL-SL5428 BOUT THE Overview The TL-SL5428 is a Fast Ethernet switch with 24 10/100BASE-TX ports and four Gigabit combination ports that are comprised of an RJ-45 port and an SFP transceiver slot. The switch also includes an SNMP-based management agent embedded on the main board. This agent supports both in-band and out-of-band access for managing the switch. -
Page 12: About The Tl-Sl5428
This prevents errors from being propagated throughout the network. Network Management Options The TL-SL5428 switch contains a comprehensive array of LEDs for “at-a-glance” monitoring of network and port status. It also includes a management agent that allows you to configure or monitor the switch using its embedded management software, or via SNMP applications. -
Page 13: Sfp Slots
RJ-45 port or SFP slot, as required. Port and System Status LEDs The TL-SL5428 includes a display panel for key system and port indications that simplify installation and network troubleshooting. The LEDs, which are located on the front panel for easy viewing, are shown below and described in the following tables. -
Page 14: Table 1-1 Port Status Leds
TL-SL5428 BOUT THE Table 1-1 Port Status LEDs Condition Status RJ-45 Ports Link/ACT On/Blinking The port has established a valid 100 Mbps link. (Link/ Green Blinking indicates activity. Activity) On/Blinking The port has established a valid 10 Mbps link. Amber Blinking indicates activity. -
Page 15: Power Supply Socket
ESCRIPTION OF ARDWARE Table 1-2 System Status LEDs Condition Status On Green The unit’s internal power supply is operating (Power) normally. On Amber The unit’s internal power supply has failed. The unit has no power connected or has failed. Diag On Green The system diagnostic test has completed successfully. -
Page 16: Features And Benefits
TL-SL5428 BOUT THE Features and Benefits Connectivity • 24 10/100BASE-TX ports plus four Gigabit combination ports (RJ-45/SFP). • Auto-negotiation enables each RJ-45 port to automatically select the optimum speed (10 or 100 Mbps), and the communication mode (half or full duplex) if this feature is supported by the attached device;... -
Page 17: Management
EATURES AND ENEFITS • Supports wire-speed filtering and forwarding • Supports flow control, using back pressure for half duplex and IEEE 802.3x for full duplex • Broadcast storm control Management • “At-a-glance” LEDs for easy troubleshooting • Network management agent: Manages switch in-band or out-of-band Supports Telnet, SNMP/RMON, and Web-based interface... - Page 18 TL-SL5428 BOUT THE...
-
Page 19: Network Planning
HAPTER ETWORK LANNING Introduction to Switching A network switch allows simultaneous transmission of multiple packets via non-crossbar switching. This means that it can partition a network more efficiently than bridges or routers. The switch has, therefore, been recognized as one of the most important building blocks for today’s networking technology. -
Page 20: Application Examples
ETWORK LANNING Application Examples The TL-SL5428 switch is not only designed to segment your network, but also to provide a wide range of options in setting up network connections. Some typical applications are described below. Collapsed Backbone The TL-SL5428 switch is an excellent choice for Ethernet, Fast Ethernet, and Gigabit Ethernet installations where significant growth is expected in the near future. -
Page 21: Network Aggregation Plan
Network Aggregation Plan With 28 parallel bridging ports (i.e., 28 distinct collision domains), the TL-SL5428 switch can collapse a complex network down into a single efficient bridged node, increasing overall bandwidth and throughput. In the figure below, the 10/100BASE-TX ports are providing 100 Mbps connectivity through layer 2 switches. -
Page 22: Remote Connections With Fiber Cable
ETWORK LANNING Remote Connections with Fiber Cable Fiber optic technology allows for longer cabling than any other media type. A 1000BASE-SX (MMF) link can connect to a site up to 550 meters away, a 1000BASE-LX (SMF) link up to 5 km, and a 1000BASE-ZX link up to 100 km. -
Page 23: Making Vlan Connections
PPLICATION XAMPLES Making VLAN Connections This switch supports VLANs which can be used to organize any group of network nodes into separate broadcast domains. VLANs confine broadcast traffic to the originating group, and can eliminate broadcast storms in large networks. This provides a more secure and cleaner network environment. -
Page 24: Application Notes
ETWORK LANNING Application Notes 1. Full-duplex operation only applies to point-to-point access (such as when a switch is attached to a workstation, server or another switch). When the switch is connected to a hub, both devices must operate in half-duplex mode. 2. -
Page 25: Installing The Switch
HAPTER NSTALLING THE WITCH Selecting a Site Switch units can be mounted in a standard 19-inch equipment rack or on a flat surface. Be sure to follow the guidelines below when choosing a location. • The site should: be at the center of all the devices you want to link and near a power outlet. -
Page 26: Ethernet Cabling
NSTALLING THE WITCH Ethernet Cabling To ensure proper operation when installing the switch into a network, make sure that the current cables are suitable for 10BASE-T, 100BASE-TX or 1000BASE-T operation. Check the following criteria against the current installation of your network: •... -
Page 27: Equipment Checklist
After unpacking this switch, check the contents to be sure you have received all the components. Then, before beginning the installation, be sure you have all other necessary installation equipment. Package Contents • TL-SL5428 • Four adhesive foot pads • Bracket Mounting Kit containing two brackets and eight screws for attaching the brackets to the switch •... -
Page 28: Mounting
NSTALLING THE WITCH Mounting This switch can be mounted in a standard 19-inch equipment rack or on a desktop or shelf. Mounting instructions for each type of site follow. Rack Mounting Before rack mounting the switch, pay particular attention to the following factors: •... -
Page 29: Figure 3-2 Attaching The Brackets
OUNTING To rack-mount devices: 1. Attach the brackets to the device using the screws provided in the Bracket Mounting Kit. Figure 3-2 Attaching the Brackets 2. Mount the device in the rack, using four rack-mounting screws (not provided). Figure 3-3 Installing the Switch in a Rack... -
Page 30: Desktop Or Shelf Mounting
NSTALLING THE WITCH 3. If installing a single switch only, turn to “Connecting to a Power Source” at the end of this chapter. 4. If installing multiple switches, mount them in the rack, one below the other, in any order. Desktop or Shelf Mounting 1. -
Page 31: Installing An Optional Sfp Transceiver
SFP T NSTALLING AN PTIONAL RANSCEIVER Installing an Optional SFP Transceiver Figure 3-5 Installing an SFP Transceiver into a Slot The SFP slots support the following optional SFP transceivers: • 1000BASE-SX • 1000BASE-LX • 1000BASE-ZX To install an SFP transceiver, do the following: 1. -
Page 32: Connecting To A Power Source
NSTALLING THE WITCH Connecting to a Power Source To connect a switch to a power source: 1. Insert the power cable plug directly into the power socket located at the back of the switch. Figure 3-6 Power Socket 2. Plug the other end of the cable into a grounded, 3-pin, AC power source. -
Page 33: Connecting To The Console Port
ONNECTING TO THE ONSOLE Connecting to the Console Port The DB-9 serial port on the switch’s rear panel is used to connect to the switch for out-of-band console configuration. The command-line-driven configuration program can be accessed from a terminal or a PC running a terminal emulation program. - Page 34 NSTALLING THE WITCH 3-10...
-
Page 35: Making Network Connections
ONNECTIONS Connecting Network Devices The TL-SL5428 switch is designed to interconnect multiple segments (or collision domains). It can be connected to network cards in PCs and servers, as well as to hubs, switches or routers. It may also be connected to remote devices using the optional SFP transceivers. -
Page 36: Connecting To Pcs, Servers, Hubs And Switches
AKING ETWORK ONNECTIONS Connecting to PCs, Servers, Hubs and Switches 1. Attach one end of a twisted-pair cable segment to the device’s RJ-45 connector. Figure 4-1 Making Twisted-Pair Connections 2. If the device is a network card and the switch is in the wiring closet, attach the other end of the cable segment to a modular wall outlet that is connected to the wiring closet. -
Page 37: Network Wiring Connections
WISTED EVICES Network Wiring Connections Today, the punch-down block is an integral part of many of the newer equipment racks. It is actually part of the patch panel. Instructions for making connections in the wiring closet with this type of equipment follows. -
Page 38: Fiber Optic Sfp Devices
AKING ETWORK ONNECTIONS Fiber Optic SFP Devices An optional Gigabit SFP transceiver (1000BASE-SX, 1000BASE-LX, or 1000BASE-ZX) can be used for a backbone connection between switches, or for connecting to a high-speed server. Each single-mode fiber port requires 9/125 micron single-mode fiber optic cable with an LC connector at both ends. -
Page 39: Connectivity Rules
ONNECTIVITY ULES Figure 4-3 Making Fiber Port Connections 4. As a connection is made, check the Link LED on the switch corresponding to the port to be sure that the connection is valid. The 1000BASE-SX, 1000BASE-LX, 1000BASE-ZX fiber optic ports operate at 1 Gbps, full duplex, with auto-negotiation of flow control. -
Page 40: 1000Base-T Cable Requirements
AKING ETWORK ONNECTIONS 1000BASE-T Cable Requirements All Category 5 UTP cables that are used for 100BASE-TX connections should also work for 1000BASE-T, providing that all four wire pairs are connected. However, it is recommended that for all critical connections, or any new cable installations, Category 5e (enhanced Category 5) or Category 6 cable should be used. -
Page 41: 100 Mbps Fast Ethernet Collision Domain
ONNECTIVITY ULES Table 4-4 Maximum 1000BASE-ZX Gigabit Ethernet Cable Length Fiber Size Fiber Maximum Cable Connector Bandwidth Length 9/125 micron 70 - 100 km single-mode fiber (43.5 - 62.1 miles) * For link spans exceeding 70 km, you may need to use premium single mode fiber or dispersion shifted single mode fiber 100 Mbps Fast Ethernet Collision Domain Table 4-5 Maximum Fast Ethernet Cable Length... -
Page 42: Cable Labeling And Connection Records
AKING ETWORK ONNECTIONS Cable Labeling and Connection Records When planning a network installation, it is essential to label the opposing ends of cables and to record where each cable is connected. Doing so will enable you to easily locate inter-connected devices, isolate faults and change your topology without need for unnecessary time consumption. -
Page 43: Troubleshooting
PPENDIX ROUBLESHOOTING Diagnosing Switch Indicators Table A-1 Troubleshooting Chart Symptom Action PWR LED is Off • Power supply is disconnected. • Check connections between the switch, the power cord and the wall outlet. • Contact your dealer for assistance. PWR LED is Amber •... -
Page 44: Power Supply Problems
ROUBLESHOOTING Power Supply Problems If the power indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply. However, if the unit powers off after running for a while, check for loose power connections, power losses or surges at the power outlet. -
Page 45: Cables
PPENDIX ABLES Twisted-Pair Cable and Pin Assignments For 10/100BASE-TX connections, the twisted-pair cable must have two pairs of wires. For 1000BASE-T connections the twisted-pair cable must have four pairs of wires. Each wire pair is identified by two different colors. For example, one wire might be green and the other, green with white stripes. -
Page 46: 10Base-T/100Base-Tx Pin Assignments
ABLES 10BASE-T/100BASE-TX Pin Assignments Use unshielded twisted-pair (UTP) or shielded twisted-pair (STP) cable for RJ-45 connections: 100-ohm Category 3 or better cable for 10 Mbps connections, or 100-ohm Category 5 or better cable for 100 Mbps connections. Also be sure that the length of any twisted-pair connection does not exceed 100 meters (328 feet). -
Page 47: Straight-Through Wiring
WISTED ABLE AND SSIGNMENTS Straight-Through Wiring If the twisted-pair cable is to join two ports and only one of the ports has an internal crossover (MDI-X), the two pairs of wires must be straight-through. (When auto-negotiation is enabled for any RJ-45 port on this switch, you can use either straight-through or crossover cable to connect to any device type.) You must connect all four wire pairs as shown in the following diagram to... -
Page 48: 1000Base-T Pin Assignments
ABLES EIA/TIA 568B RJ-45 Wiring Standard 10/100BASE-TX Crossover Cable White/Orange Stripe Orange White/Green Stripe End A End B Blue White/Blue Stripe Green White/Brown Stripe Brown Figure B-3 Crossover Wiring 1000BASE-T Pin Assignments All 1000BASE-T ports support automatic MDI/MDI-X operation, so you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs. -
Page 49: 1000Base-T Cable Requirements
WISTED ABLE AND SSIGNMENTS Table B-2 1000BASE-T MDI and MDI-X Port Pinouts MDI Signal Name MDI-X Signal Name Bi-directional Data One Plus (BI_D1+) Bi-directional Data Two Plus (BI_D2+) Bi-directional Data One Minus (BI_D1-) Bi-directional Data Two Minus (BI_D2-) Bi-directional Data Two Plus (BI_D2+) Bi-directional Data One Plus (BI_D1+) Bi-directional Data Three Plus (BI_D3+) Bi-directional Data Four Plus (BI_D4+) -
Page 50: Fiber Standards
ABLES Note that when testing your cable installation, be sure to include all patch cables between switches and end devices. Adjusting Existing Category 5 Cabling to Run 1000BASE-T If your existing Category 5 installation does not meet one of the test parameters for 1000BASE-T, there are basically three measures that can be applied to try and correct the problem: 1. -
Page 51: Specifications
PPENDIX PECIFICATIONS Physical Characteristics Ports 24 10/100BASE-TX, with auto-negotiation 4 Combination Gigabit Ports (RJ-45/SFP) Network Interface Ports 1-24: RJ-45 connector, auto MDI/X 10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better) 100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better) Ports 25-28: RJ-45 connector, auto MDI/X 1000BASE-T: RJ-45 (100-ohm, UTP cable;... -
Page 52: Switch Features
PECIFICATIONS Size 44 x 17.1 x 4.3 cm (17.3 x 6.7 x 1.7 in.) Temperature Operating: 0 °C to 40 °C (32 °F to 104 °F) Storage: -40 °C to 70 °C (-40 °F to 158 °F) Humidity Operating: 10% to 90% (non-condensing) Power Supply Internal, auto-ranging transformer: 100 to 240 VAC, 50 to 60 Hz, 0.8 A Power Consumption... -
Page 53: Management Features
ANAGEMENT EATURES Management Features In-Band Management Web, Telnet, SSH, or SNMP manager Out-of-Band Management RS-232 DB-9 console port Software Loading TFTP in-band, or XModem out-of-band Standards IEEE 802.3-2005 Ethernet, Fast Ethernet, Gigabit Ethernet Full-duplex flow control IEEE 802.1D Spanning Tree Protocol IEEE 802.3x full-duplex flow control IEEE 802.1w Rapid Spanning Tree Protocol IEEE 802.1Q (Virtual LAN) - Page 54 PECIFICATIONS Immunity EN 61000-4-2/3/4/5/6/8/11 Safety CSA (CSA 22.2 NO60950-1) CB (IEC 60950-1)
- Page 55 LOSSARY 10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3, 4, or 5 UTP cable. 100BASE-TX IEEE 802.3u specification for 100 Mbps Ethernet over two pairs of Category 5 UTP cable. 1000BASE-LX IEEE 802.3z specification for Gigabit Ethernet over two strands of 50/ 125, 62.5/125 or 9/125 micron core fiber cable.
- Page 56 Bandwidth The difference between the highest and lowest frequencies available for network signals. Also synonymous with wire speed, the actual speed of the data transmission along the cable. Collision A condition in which packets transmitted over the cable interfere with each other.
- Page 57 Full Duplex Transmission method that allows two network devices to transmit and receive concurrently, effectively doubling the bandwidth of that link. Gigabit Ethernet A 1000 Mbps network communication system based on Ethernet and the CSMA/CD access method. IEEE Institute of Electrical and Electronic Engineers. IEEE 802.3 Defines carrier sense multiple access with collision detection (CSMA/CD) access method and physical layer specifications.
- Page 58 Light emitting diode used for monitoring a device or network condition. Local Area Network (LAN) A group of interconnected computer and support devices. Media Access Control (MAC) A portion of the networking protocol that governs access to the transmission medium, facilitating the exchange of data between network nodes.
- Page 59 Telecommunications Industry Association Transmission Control Protocol/Internet Protocol (TCP/IP) Protocol suite that includes TCP as the primary transport protocol, and IP as the network layer protocol. Unshielded twisted-pair cable. Virtual LAN (VLAN) A Virtual LAN is a collection of network nodes that share the same collision domain regardless of their physical location or connection point in the network.
- Page 60 Glossary-6...
- Page 61 NDEX Numerics 10 Mbps 4-8 100 Mbps 4-7 10 Mbps connectivity rules 4-8 1000 Mbps 4-6 100 Mbps connectivity rules 4-7 console port 1000 Mbps connectivity rules 4-6 pin assignments 3-9 1000BASE-LX fiber cable lengths 4-7 contents of package 3-3 1000BASE-SX fiber cable lengths 4-7 cord sets, international 3-8 100BASE cable lengths 4-7...
- Page 62 NDEX installation connecting devices to the switch 4-2 desktop or shelf mounting 3-6 package contents 3-3 network wiring connections 4-3 pin assignments B-1 port connections 4-1 1000BASE-T B-4 power requirements 3-1 10BASE-T/100BASE-TX B-2 problems A-2 console port 3-9 site requirements 3-1 DB-9 3-9 wiring closest connections 4-3 ports, connecting to 4-1...
- Page 63 NDEX method 1-2 twisted-pair connections 4-1 Telnet A-2 VLANs, tagging 2-5 temperature within a rack 3-4 troubleshooting in-band access A-2 switch indicators A-1 Web-based management 1-2 Index-3...
- Page 64 TP-LINK TECHNOLOGIES CO., LTD. http:// www.tp-link.com...
