Port Trunking

How the Switch Lists Trunk Data

12-26
How the Switch Lists Trunk Data
Static Trunk Group: Appears in the menu interface and the output from the
CLI show trunk and show interfaces commands.
Dynamic LACP Trunk Group: Appears in the output from the CLI show lacp
command.
Interface Option
Menu Interface
CLI show trunk
CLI show interfaces
CLI show lacp
CLI show spanning-tree
CLI show igmp
CLI show config
Outbound Traffic Distribution Across
Trunked Links
The two trunk group options (LACP and Trunk) use source-destination
address pairs (SA/DA) for distributing outbound traffic over trunked links.
SA/DA (source address/destination address) causes the switch to distribute
outbound traffic to the links within the trunk group on the basis of source/
destination address pairs. That is, the switch sends traffic from the same
source address to the same destination address through the same trunked link,
and may also send traffic from the same source address to a different desti­
nation address through the same link or a different link, depending on the
mapping of path assignments among the links in the trunk. Likewise, the
switch distributes traffic for the same destination address but from different
source addresses through links depending on the path assignment.
Dynamic LACP Static LACP
Trunk Group Trunk Group
No Yes
No Yes
No Yes
Yes Yes
No Yes
No Yes
No Yes
Static Non-Protocol
Yes
Yes
Yes
No
Yes
Yes
Yes
