Hotswapping Management Modules

Hotswapping Out the Active Management Module

You can hotswap out the active management module and have switch
operations taken over by the standby management module by following the
correct shutdown procedure on the active module using the MM Shutdown
button. When the MM Shutdown button is pressed on the active management
module, any file synchronization in progress completes before the shutdown
begins, and then a graceful shutdown of that management module occurs.
If redundancy is enabled, all the files on the hotswapped module are
overwritten with files from the active management module. The data that was
on the hotswapped module is lost.
1. On the management module to be hotswapped out, press the MM Shut­
down button. It is located between the Module Operation and Component
Status LEDs. See Figure 15-9.
Figure 15-9. The MM Shutdown Button
2. The Dwn LED to the right of the MM Shutdown button will begin flashing
green. File synchronization will complete before shutdown occurs.
3. The standby module takes control and the switchover occurs. It is now
the active management module.
4. The Dwn LED on the management module being hotswapped out turns
green and all other LEDs go out when it is OK to remove the module.
5. The module being hotswapped out goes into offline mode. In the "offline"
mode, the module cannot take over when the active module fails over.
