Comtech EF Data CDM-700 Installation And Operation Manual page 159

CDM-700 High Speed Satellite Modem
Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Tx Alpha TAR= 1 byte
Rolloff
Tx Spectrum TSI= 1 byte
Invert
Tx Scrambler TSC= 1 byte
Tx Power TPL= 5 bytes
Level
Tx Output IMP= 1 byte
Impendance
Description of Arguments
to Query
Command or Query
Tx Alpha Rolloff, where:
1 = 25%
2 = 35%
Example: TAR=1 (which is a Tx Alpha Rolloff of 25%)
Command or Query.
Tx Spectrum Invert selection, where:
0=Normal,
1=Tx Spectrum Inverted
Example: TSI=0 (which is normal)
Command or Query.
Tx Scrambler state, where:
0=Off
1=On
Example: TSC=1 (Scrambler On)
Command or Query.
Tx Output power level, where:
s=sign ( + / - )
xx.x = Tx Output power level,
L-Band unit: +00.0 and –20.0 dBm.
70/140 MHz unit: +00.0 to –20.0 dBm
Note: Beyond –20 dBm is beyond the specification.
Example: TPL = -13.4
Command or Query.
Tx output impedance, where:
0=50 Ohm
1=75 Ohm
(Valid for 70/140 MHz units only)
Example: IMP=1 (Set impedance to 75 Ohms)
Response to
Command
TAR=
TAR?
TAR*
TAR#
TSI=
TSI?
TSI*
TSI#
TSC=
TSC?
TSC*
TSC#
TPL=
TPL?
TPL*
TPL#
IMP=
IMP?
IMP*
IMP#
11–9
Revision 5
MN/CDM700.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
TAR? TAR=x
(see description of
arguments)
TSI? TSI=x
(see description of
arguments)
TSC? TSC=x
(see description of
arguments)
TPL? TPL=sxx.x
(see description of
arguments)
IMP? IMP=x
(see description of
arguments)
