Chapter 6. FRONT PANEL
OPERATION
6.1
Introduction
LED
Vacuum Fluorescent
Indicators
Keypad
Display (VFD)
Figure 6-1. Front Panel View
Operators can fully control and monitor the operation of the CDM-700 from the front panel using
the keypad and display. Nested menus display all available options, prompting operators to carry
out a required action.
Figure 6-1 identifies the key features of the front panel, which are explained in greater detail in
this section.
