Comtech EF Data CDM-700 Installation And Operation Manual page 173

CDM-700 High Speed Satellite Modem
Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Frame Error N/A 9bytes
Rate
Rx BER BTH 1bytes
Alarm
Threshold
Local/Remote LRS= 1 byte
Status
Software N/A 34 bytes
Revision
Description of Arguments
to Query
Query only.
s=Defines which interface slot ( 1 or 2 )
Units returns the value of the calculated estimated Frame Error
Rate(LINK ERRORS/RX PACKETS RECEIVED) in the form a.b
-c
x 10 . First three bytes are the value. Last two bytes are the
exponent. Returns 0.0E+00 0r 1.0E+00 if the Gigabit Traffic is
RX PACKETS Received 0..
Example: FER=17.8E-03 (which is Slot One FER= 7.8 x 10
Valid for Gigbait Interface Only.
Value is reset to 0.00E+00 if GBEI Statistics Cleared.
Command or Query.
Sets and Returns BerThreshold
a=Ber Threshold
0= NONE
3= 1E10-3
4 =1E10-4
5= 1E10-5
6= 1E10-6
7= 1E10-7
8 =1E10-8
Example BTH=3(Sets Ber Alarm Threshold to 1E10-3)
Command or Query.
Local/Remote status, where:
0=Local
1=Serial
2=Reserved
3=Ethernet
Example: LRS=1 (which is Serial Remote)
Query only.
Unit returns the value of the internal software revision installed in
the unit, in the form of x.x.x
Example: SWR=Boot:1.0.1 Bulk1:1.0.1 Bulk2:1.0.1
Response to
Command
N/A
-3
)
BTH=
BTH?
BTH#
LRS=
LRS?
LRS*
LRS#
N/A
11–23
Revision 5
MN/CDM700.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
FER?s FER=sa.bExcc
BTH? BTH =
1E10-3
Returns string of BER Alarm
Threshold
LRS? LRS=x
SWR? SWR=Boot:x.x.x
Bulk1:x.x.x Bulk2:x.x.x
