1.1

Overview

The Comtech EF Data CDM-700 High Speed Satellite Modem (Figure 1-1) – hereinafter
referred to as "the modem" – is intended for simplex or duplex operations with a range of
multi-port data interfaces. The modem operates in broadcast, circuit restoration, point-to-point
and point-to-multipoint applications.
Chassis – Initially released version
Chassis –Rev. A or later version
Item
1:1 and 1:N Redundancy
Front Panel

Chapter 1. INTRODUCTION

Rev A or Later Version
Supports 1:1 and 1:N Redundancy
Protruding Round Button + Arrow Keys

Figure 1-1. CDM-700 High Speed Satellite Modem

Initially released Version
Single Thread Only.
Not Field Upgradable.
Diamond Shape Flat Membrane Keys
1–1
