Comtech EF Data CDM-700 Installation And Operation Manual page 168

CDM-700 High Speed Satellite Modem
Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Interface IAM= 7 bytes
Alarm Mask
HSSI Interface HAM= 7 bytes
Alarm Mask
Description of Arguments
to Query
Command or Query.
Alarm mask conditions, in form spabcdef, where:
s=slot number
p=port number
a=Tx Cable (0 = masked as Alarm,1 = masked as Fault,2 =Masked)
b=Tx AIS (0 = masked as Alarm,1 = masked as Fault,2 =Masked)
c=Rx AIS (0 = masked as Alarm,1 = masked as Fault,2 =Masked)
d=Bufferslip Alarm (0 = masked as Alarm,1 = masked as Fault,
2 =Masked)
e=External Clock Alarm (0 = masked as Alarm,1 = masked as
Fault,2 =Masked)
(Note: Command valid Only with CDI-10 Dual G.703 interface)
Example: IAM=1101011 ( alarm masks for interface slot 1, port 1 )
Command or Query.
Alarm mask conditions, in form spa, where:
s=slot number
p=port number
21
a=x reserved
b=x reserved
c=x reserved
d=x reserved
e=Ext Clock Alarm (0 = masked as Alarm,1 = masked as Fault,2
=Masked) (Note: Command valid Only with Gigabit Interface)
Example: HAM= 21xxxx0 ( alarm masks for interface slot 2, port 1 )
Response to
Command
IAM=
IAM?
IAM*
IAM#
HAM=
HAM?
HAM*
HAM#
11–18
Revision 5
MN/CDM700.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
IAM?sp IAM=spabcde
HAM?sp HAM=spxxxxe
