Comtech EF Data CDM-700 Installation And Operation Manual page 166

CDM-700 High Speed Satellite Modem
Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Rx Buffer Size RBS= 6 bytes
Rx Buffer RFM= 3 bytes
Frame
External ERF= 1 byte
Reference
Frequency
( Modem
Reference
Clock )
Description of Arguments
to Query
Command or Query.
Rx Buffer Size (in milliseconds), where:
s=Defines which interface slot ( 1 or 2 )
c=Defines which channel ( 1 to 2 )
xx.x=Rx Buffer Size,
E3 mode = 0.5 to 61.0 ms, in 0.5 ms steps
T3 mode = 0.5 to 44.0 ms, in 0.5 ms steps
STS1 mode = 0.5 to 40.0 ms, in 0.5 ms steps
HSSI interface = 5.0 to 32.0 ms, in 0.1 ms steps
OC-3 interface = 2.0 to 26.0 ms, in 0.1 ms steps
GBEI interface = N/A
Example: RBS=1130.0 (selects 30.0 ms on interface 1, channel 1)
Command or Query. (G.703 Parameters)
Rx Buffer Frame, where:
s=Defines which interface slot ( 1 or 2 )
c=Defines which channel ( 1 to 2 )
x=Rx Ternary Code, where:
0=None ( Valid for E3, T3, and STS-1 )
1=G.751 (Valid for E3 )
2=G.752 (Valid for T3 )
3=G.753 (Valid for E3 )
4=STS-1 (Valid for STS-1 )
(Note: Command valid Only with CDI-10 Dual G.703 interface)
Example: RFM=111 (selects G.751 for slot #1, channel #1)
Command or Query.
External Reference Frequency (For Frequency Accuracy), where:
0=Internal 10 MHz
1=External 1 MHz
2=External 2 MHz
3=External 5 MHz
4=External 10 MHz
5=External 20 MHz
Example: ERF=5 (selects External Reference Frequency to be 20 Mhz)
Response to
Command
RBS=
RBS?
RBS*
RBS#
RFM=
RFM?
RFM*
RFM#
ERF=
ERF?
ERF*
ERF#
11–16
Revision 5
MN/CDM700.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
RBS?sc RBS=scxx.x
(see description of
arguments)
RFM?sc RFM=scx
(see description of
arguments)
ERF? ERF=x
