CDM-700 High Speed Satellite Modem
SNMP Interface
12.8.1 E3T3STS1 Group
The CDM-700 E3T3STST1 Group holds all unit parameters associated with the E3/T3/STS1
Interface. For detailed information, refer to the actual MIB file.
12.8.2 OC3 Group
The CDM-700 OC3 Group holds all unit parameters associated with the OC3 Interface. For
detailed information, refer to the actual MIB file.
12.8.3 HSSI Group
The CDM-700 HSSI Group holds all unit parameters associated with the HSSI Interface. For
detailed information, refer to the actual MIB file.
12.8.4 Gigabit Ethernet Group
The CDM-700 Gigabit Ethernet Group holds all unit parameters associated with the Gigabit
Ethernet Interface. For detailed information, refer to the actual MIB file.
12.9
CDM Monitor Objects
The CDM-700 Monitor Objects holds all unit, transmit and receive alarms associated with the
notifications for support Of SNMP v1.2 and SNMP v2.0 Traps. For detailed information, refer to
the actual MIB file.
12.10 CDM Redundancy Objects
The CDM-700 Redundancy Objects holds all the entries associated with monitoring of the
Redundancy Modes of the modem. For detailed information, refer to the actual MIB file.
12.11 SNMP Traps
The CDM-700 has the ability to send out SNMP traps when certain events occur in the modem.
For example: When the CDM-700 boots, it sends out a coldstart trap and three linkup traps – one
for each interface that is brought up.
The CDM-700 also sends out traps when an alarm or a fault occurs in the modem. These include
Unit faults, TX faults, and RX faults. A trap is sent for both when a fault occurs and when the
fault condition changes.
The CDM-700 supports both SNMPv1 traps and SNMPv2 notifications. Which style of traps the
CDM-700 sends can be configured by the user using the cdmipSnmpTrapVersion OID.
12–5
Revision 5
MN/CDM700.IOM
