CDM-700 High Speed Satellite Modem
Flash Upgrading
IMPORTANT
9.2

Base Modem FTP upload procedure:

1. Identify the reflashable product, firmware number, and version for download.
The current base modem M&C version can be viewed at the top-level menu of the front
panel display (press
information within the
Using serial remote control, you can query the firmware revision levels with the
2. Create a temporary directory (folder) on your PC.
Windows:
another convenient and unused name. Assuming "temp" works, you should now have a
"c:\temp" folder created.
Alternative Method – CMD Prompt: At the command prompt (c:\>) type "MD temp"
without quotes (MD stands for make directory). This is the same as creating a new folder
from Windows. You should now have a "c:\temp" subdirectory created, where c: is the
drive letter used in the example.
3. Download the correct firmware file to this temporary folder.
Access the download server with the flash firmware data files link:
http://206.223.8.10/linksite/flashupgrades/CDM700/
-or-
(*Note: Choices shown are representative of upgrades available via the Web as of 4/2008. These selections
are updated periodically. Contact Comtech EF Data Customer Support for questions regarding the availability of
support files for your specific product.)
The procedure for updating the CDI-70 (via J4 Ethernet) Gigabit Ethernet
Interface firmware is outlined in Appendix E. 10/100/1000 BASE-T
INTERFACE (GbEI) (CDI-70).
CLR
button several times to view). Also, you can find the firmware
Util Firmware
<0/SWR? Command. (Abbreviated)
<0/FRW? Command (Detailed)
Select File New
Note: The c: is the drive letter used in this example. Any valid writable drive
letter can be used.
a) Go online to:
www.comtechefdata.com
b) Click on: Support
c) Click on: Software Downloads
d) Click on: Flash Update Files
e) Click on: <dir> CDM700_700L
f) Select:
F10236K V123
Info Image#1, Image#2
Or
Folder and rename the New Folder to "temp" or
111607*
9–2
Revision 5
MN/CDM700.IOM
menu tree.
