CDM-700 High Speed Satellite Modem
Front Panel Operation
Intfc1 Gigabit Ethernet:
Intfc1 Management IP:
192.168.001.001/30 (
Edit the Gigabit Ethernet Interface Management IP Address and Mask Range by selecting the digit
to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the ▲ ▼
arrow keys.
This is the IP address that can be used for 1 of 2 purposes:
•
First, PING can be used with this IP address as a diagnostic tool to ensure the
interface is active and the external cabling in properly connected.
•
Second, this is the IP address that will be used in the event that new firmware is
provided by CEFD for the CDI-70 Gigabit Ethernet interface.
Once the Gigabit Ethernet Interface Management IP Address and Mask Range are edited, Press
.
ENTER
Intfc1 Gigabit Ethernet:
Intfc1 Statistics:
View
Select View or Clear using the
If Intfc1 Statistics:
FPGA Link Errors
00000000000000000000 (▲ ▼ E)
Use the ▲ ▼ arrow keys to scroll through the available statistics and counters.
Man
Stats
Clear (
◄ ►
arrow keys. Press
View is selected:
▲ ▼ E)
E)
.
ENTER
6–41
Revision 5
MN/CDM700.IOM
