CDM-700 High Speed Satellite Modem
Front Panel Operation
Category
Mng Undersize (In)
Mng Collisions (In)
Mng Fragments (In)
Mng Oversize (In)
Mng Jabber (In)
Mng Discards (In)
Mng Rx Err (In)
Mng FCS Err (In)
Mng Octets (Out)
Mng Unicast (Out)
Mng Broadcast (Out)
Mng Multicast (Out)
Intfc1 Gigabit Ethernet:
Intfc1 SWOP:
AutoCx Learning Mode
This section describes the menu selections for setting up VLAN operation when SWOP (Switch
Operation) is selected from the (CONFIG:) Intfc1 Gigabit Ethernet: menu.
Select AutoCx, Learning, or Mode using the
If Intfc1 SWOP:
Intfc1 Auto Crossover:
Enable
If enabled, the Gigabit Ethernet Interface automatically detects the type of connection and
configures the interface appropriately as straight-through (MDI) or crossover (MDIX).
If disabled, the Gigabit Ethernet port is configured as straight-through (MDI).
Select Enable or Disable using the ◄ ► arrow keys. Press
GBEI Statistics Summary
Message
Removed, V1.3.1 and later
The sum of collisions detected on the WAN
Total frames received from the local GBEI management processor
with a length of less than 64 octets and an invalid FCS
Total frames received form the local GBEI management processor
with a length greater than the maximum size of octets but with a valid
FCS
Removed, V1.3.1 and later
The number of management processor packets that have been
discarded due to GBEI switch congestion
Total frames received from the local GBEI management processor
for which an error was detected by its physical interface
Total frames received from the local GBEI management processor
with a CRC error which was not counted in the Fragments or Rx Err
totals
The sum of the lengths of all Ethernet frames transmitted to the local
GBEI management processor
The sum of frames transmitted to the local GBEI management
processor that have a unicast destination MAC address
The sum of frames transmitted to the local GBEI management
processor that have a broadcast destination MAC address
The sum of frames transmitted to the local GBEI management
processor that have a multicast destination MAC address
SWOP (Switch Operation)
AutoCx is selected:
Disable (
6–44
Description
( E)
◄ ►
arrow keys. Press
E)
ENTER
