Comtech EF Data CDM-700 Installation And Operation Manual page 165

CDM-700 High Speed Satellite Modem
Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Rx Interface RIE= 3 bytes
Enable
Rx Clock RCK= 3 bytes
Source
Interface EFI= 2 bytes
Reference
Clock
Eb/No Alarm EBA= 4 bytes
Point
Description of Arguments
to Query
Command or Query.
Interface Channel Enable/Disable, where:
s=Defines which interface slot ( 1 or 2 )
c=Defines which channel ( 1 to 2 )
x=Rx Interface Status, where:
0=Disabled
1=Enabled
Example: RIE = 111 (Enables receive on interface slot 1, channel 1)
Command or Query.
Rx Clock Source (For Data Rate Accuracy), where:
s=Defines which interface slot ( 1 or 2 )
c=Defines which channel ( 1 to 2 )
x=Rx Clock Source, where:
0=Rx Satellite
1=Tx-Terrestrial
2=External Reference Clock (CDI-10 Only)
3=Internal (CDI-50 OC-3 and CDI-60 HSSI Only)
Example: RCK=111 (selects Tx-Terrestrial)
Command or Query.
s=Defines which interface slot (1 or 2)
x=EXT CLK (Data Rate Accuracy), where:
0 = 1 MHz
1 = 2 MHz
2 = 2.048 MHz
3 = 5 MHz
4 = 10 MHz
5 = 20 MHz
6 = 34.368 MHz
7 = 44.736 MHz
8 = 51.840 MHz
(Note: Command valid Only with CDI-10 Dual G.703 interface)
Example: EFI=14 (Selects 10MHz on slot 1)
Command or Query.
Eb/No alarm point in dB, with a range between 0.1 and 16 dB.
Resolution=0.1 dB
Example: EBA=12.3
Response to
Command
RIE=
RIE?
RIE*
RIE#
RCK=
RCK?
RCK*
RCK#
EFI=
EFI?
EFI*
EFI#
EBA=
EBA?
EBA*
EBA#
11–15
Revision 5
MN/CDM700.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
RIE?sc RIE=scx
(see description of
arguments)
RCK?sc RCK=scx
(see description of
arguments)
EFI?s EFI=sx
(see description of
arguments)
EBA? EBA=xx.x
(see description of
arguments)
