CDM-700 High Speed Satellite Modem
Introduction
1.2.2 Turbo Product Coding (TPC)
The modem has Turbo Product Coding (TPC) available. TPC simultaneously offers increased
coding gain and lowers decoding delay. The TPC rates are:
Rate 3/4
Rate 7/8
1.3
Major Assemblies
Later Unit
Part Number
PL/12000-1
PL/10002-1
PL/10003-1
PL/10003-2
PL/12113-1
PL/11571-1
PL/10004-1
Data Interface Modules
PL/10008-1
PL/11043-1
PL/11043-2 (Note 2)
PL/11582-1 (Note 3)
PL/11509-1
(Initially released units)
PL/11509-3
(Rev. A and later units)
KT/12139-1
Notes:
1. Rev. A and later units required for 1:1 and 1:N Redundancy. Initially released units are
not field upgradeable.
2. Check with factory for availability.
3. The PL/11509-1 is upgradeable to PL/11509-3 (functionality with a reflash of
PL/11509-1 module via the Gigabit Ethernet port.)
1.4
Allowable Data Interface Combinations
Data interfaces are plugged into Slot 1 and Slot 2 of the CDM-700. The allowable combination of
data interfaces and the data interfaces that are supported for redundancy are listed below. The
QPSK, 8-PSK, 16-QAM, 64-QAM
QPSK, 8-PSK, 16-QAM, 64-QAM
Table 1-1. Major Assemblies
Early Unit
Item
Part Number
(See Note 1)
PL/10012-1
Framing Card
PL/10002-1
70 / 140 MHz Modulator Card
70 / 140 Demodulator Card, 75 Ω
PL/10003-1
70 / 140 Demodulator Card, 50 Ω
PL/10003-2
L-Band Modulator Card, 50 Ω
PL/11230-1
L-Band Demodulator Card, 50 Ω
PL/11571-1
PL/10004-1
Generation 3 Turbo FEC Card
CDI-10 – Dual E3 / T3 / STS-1 G.703 Data Interface Module
CDI-50-1 – Single Mode OC-3 (Optical) / STM-1 (Copper) Interface Module
CDI-50-2 – Multiple Mode OC-3 (Optical) / STM-1 (Copper) Interface Module
CDI-60 – HSSI Interface Module
CDI-70 – Gigabit Ethernet Interface Module with RJ-45 female connector
CDI-70 – Gigabit Ethernet Interface Module with RJ-45 female connector
Blank Interface Panel
1–3
Revision 5
MN/CDM700.IOM
