CDM-700 High Speed Satellite Modem
Front Panel Operation
If Community
Read Community: (
public
Edit the Read Community string using the ◄ ►
characters) is available. Select the cursor position on the bottom line using the ◄ ► arrow keys,
then edit the selected character using the
The following characters are available:
If Community
Write Community: (
private
Edit the Write Community string using the ◄ ►
characters) is available. Select the cursor position on the bottom line using the ◄ ► arrow keys,
then edit the selected character using the
The following characters are available:
If SNMP Traps is selected:
SNMP Trap IP Address:
1 2
Select 1 or 2 to access/modify the Trap/IP Address #1 or #2 using the ◄ ► arrow keys, then
press .
ENTER
If SNMP Trap IP Address:
SNMP Trap IP Address #X:
000.000.000.000 (
Edit the SNMP Trip IP#1 or IP#2 Address by selecting the digit to be edited, using the ◄ ► arrow
keys. The value of the digit is then changed using the ▲ ▼ arrow keys. Press
Read is selected:
<Space> A-Z a-z {|}!"#$%&'()*+,-./ 0123456789 :;<>?@ []^_`.
Write is selected:
<Space> A-Z a-z {|}!"#$%&'()*+,-./ 0123456789 :;<>?@ []^_`.
1 or 2 is selected:
E )
arrow keys. Only the bottom line (0 to 20
▲ ▼
arrow keys.
▲ ▼
E )
arrow keys. Only the bottom line (0 to 20
▲ ▼
arrow keys.
▲ ▼
( E )
)
6–11
Revision 5
MN/CDM700.IOM
.
