CDM-700 High Speed Satellite Modem
Front Panel Operation
Intfc1: Port2
Intfc1 Port2 E3/T3/STS1:
Type Line-Code Tx Rx (
Functionality for all submenus under (CONFIG:) Intfc1
outlined previously under (CONFIG:) Intfc1
under (CONFIG:) Intfc1
Intfc1: Ext-Clk
Intfc1 Ext-Clk Freq:
1.000 Mbps (
Set the input frequency for the Ext-Clk connector on the E3/T3/STS-1 Interface Card by using the
arrow keys. The Ext-Clk Frequency source selections are: 0 (None), 1, 2, 5, 10, 2.048,
▲ ▼
34.368, 44.736, and 51.84 MHz. The input level ranges from 0.5 to 5.0 volts peak-to-peak.
Once the Ext-Clk input frequency has been edited, Press

6.3.1.4.1 (CONFIG:) Intfc2 (CDI-10 Dual G.703 Interface)

The CDM-700 can be configured with a second CDI-10 Dual G.703 Interface board plugged into
interface Slot2 (Intfc2). The menus are identical to what is presented in 6.3.1.4 (CONFIG:) Intfc1
(CDI-10 Dual G.703 Interface) except that Intfc2, rather than Intfc1, is displayed in all menus.
E)
Port1. For a full explanation of all submenus
Port2, refer to these previous sections.
E)
6–30
Port2 is identical to what has been
.
ENTER
Revision 5
MN/CDM700.IOM
