CDM-700 High Speed Satellite Modem
Front Panel Operation
If Firmware Images: Select is selected:
Current Active Image: #2
Next Reboot Image: #1 #2
This menu is used to select the active software image. The top line shows the active image. On the
second line, select the desired image using the
selected image active, it is necessary to power cycle the modem to reboot the new software.
UTIL: FAST
FAST:Cnfg View (H/W 0.03)
MainBoard S/N: 123456789
Comtech EF Data's FAST (Fully Accessible System Topology) system permits the purchase and
installation of options through special authorization codes, entered remotely or through the front
panel. FAST allows immediate implementation of different options through the user interface
keypad. All FAST options are available through the basic platform unit.
In addition, the Hardware Revision Number, and the Main Board Serial Number are presented. This
Serial Number is a unique indentifier for the FAST upgrade process (and is different from the Chassis
Serial Number) and is required to obtain a new FAST code from the factory.
Select either Cnfg or View using the
If (UTIL:) FAST:
FAST Configuration
Edit Code
Select Edit Code or Demo Mode using the
If FAST Configuration:
Edit 20 digit FAST Code:
00000000000000000000 ENT
Enter the code carefully on the bottom line by using the ◄ ► arrow keys to move to each
character position, then editing the character in that position by using the
the 20-digit FAST Code has been correctly edited into place, press
respond with "Configured Successfully" if the new FAST option has been accepted.
If FAST Configuration:
FAST Demo Mode: Off On
604669 seconds remain
The Demo Mode enables all FAST options for seven days (604800 seconds).
arrow keys, then press
Cnfg is selected:
Demo Mode
Edit Code is selected:
Demo Mode is selected:
6–69
arrow keys, then press
ENTER
arrow keys, then press
ENTER
Revision 5
MN/CDM700.IOM
. To make the
ENTER
.
.
ENTER
arrow keys. Once
. The CDM-700 will
