Comtech EF Data CDM-700 Installation And Operation Manual page 164

CDM-700 High Speed Satellite Modem
Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Rx Spectrum RSI= 1 byte
Invert
Rx RDS= 1 byte
Descrambler
Rx Data Invert RDI= 3 bytes
Rx Clock RCI= 2 bytes
Invert
Rx Demod RSW= 3 bytes
Acquisition
Sweep Width
Description of Arguments
to Query
Command or Query.
Rx Spectrum Invert, where:
0=Normal
1=Rx Spectrum Invert
Example: RSI=0 (selects Normal)
Command or Query.
Rx Descrambler state, where:
0=Off
1=On
Example: RDS=1 (Scrambler On)
Command or Query.
Invert Receive Data, where:
s=Defines which interface slot ( 1 or 2 )
c=Defines which channel ( 1 to 2 )
x=Invert Receive Data, where:
0=Normal
1=Inverted
(Note: Command valid Only with CDI-10 Dual G.703 and CDI-60
HSSI interface. For HSSI the 'c' parameter is always '1')
Example: RDI = 111 (selects Inverted RX Data)
Command or Query.
Invert Receive Clock, where:
s=Defines which interface slot ( 1 or 2 )
x=Invert Receive Clock, where:
0=Normal
1=Inverted
(Note: Command valid Only with CDI-60 HSSI interface)
Example: RCI = 11 (selects Inverted RX Clock, Slot 1)
Command or Query.
Rx ± acquisition sweep range of demodulator, in kHz, ranging
from ± 1 to ± 100 kHz.
Example: RSW=009 (selects ± 9 kHz)
Response to
Command
RSI=
RSI?
RSI*
RSI#
RDS=
RDS?
RDS*
RDS#
RDI=
RDI?
RDI*
RDI#
RCI =
RCI?
RCI *
RCI #
RSW=
RSW?
RSW*
RSW#
11–14
Revision 5
MN/CDM700.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
RSI? RSI=x
(see description of
arguments)
RDS? RDS=x
(see description of
arguments)
RDI?sc RDI=scx
(see description of
arguments)
RCI?s RCI =sx
(see description of
arguments)
RSW? RSW=xxx
(see description of
arguments)
